Description
Product Overview
The HPE Proliant Dl360 G7 server is a 1u rack server designed for businesses and organizations that require high-performance computing and data processing capabilities. This server is equipped with a powerful 1x Xeon E5645 Quad Core processor, 6GB of RAM, and supports both SAS and SATA storage options. It also includes 4 Gigabit Ethernet ports for fast networking and data transfer speeds.
In this article, we will dive deeper into the technical specifications of the HPE Proliant Dl360 G7 server, its features, and benefits. We will also discuss how this server can be used in different business settings to improve performance and increase productivity.
Processor and Memory
The HPE Proliant Dl360 G7 is powered by a 1x Xeon E5645 Quad Core processor, which operates at a clock speed of 2.4GHz. This processor delivers high performance and processing power, allowing the server to handle complex workloads and applications with ease. With four cores and eight threads, this processor can handle multiple tasks simultaneously, making it ideal for multi-tasking environments.
The server comes with 6GB of DDR3 RAM, which is expandable up to 192GB. This allows for improved system performance and faster data processing. The server also includes SmartMemory technology, which ensures that the system memory is optimized for performance and reliability.
Management and Security
The HPE Proliant Dl360 G7 server includes various management and security features. The server includes HP’s iLO management engine, which provides remote management capabilities for the server. This allows administrators to monitor and manage the server from a remote location, reducing the need for physical access to the server.
The server also includes HP’s Integrated Lights Out (iLO) Advanced technology, which provides additional management and security features. This technology allows for advanced remote management capabilities, including virtual media, remote console, and power management. It also includes integrated lights-out encryption, which provides secure communication between the server and management console.
General Information
- Manufacturer: Hewlett Packard Enterprise(HPE)
- Manufacturer Part Number: 633777-001
- Type: Server
- Sub-Type: Proliant Dl360
- Product Name: Proliant Dl360 G7 1u Rack Mountable Server
Processor & Chipset
- Processor Type: Intel Xeon E5645/2.4 Ghz
- Multi-Core Technology: 6-Core
- 64-Bit Computing: Yes
- Installed Processor Qty: 1
- Max Supported Processor Qty: 2
- Upgradability: Upgradable
- Processor Main Features:
- Hyper-Threading Technology
- Intel Turbo Boost Technology
- Chipset Type: Intel 5520
Cache Memory
- Cache Memory Type: L3 Cache
- Installed Size: 12 Mb
- Cache Per Processor: 12 Mb
Memory
- Installed Ram Size: 6 Gb
- Max Supported Size : 144 Gb
- Technology: Ddr3 Sdram
- Memory Speed: 1333 Mhz
- Memory Specification Compliance: Pc3-10600
- Form Factor: Dimm 240-Pin
- Features: Registered
- Configuration Features: 3 X 2 Gb
- Ram Supported:
- Pc3-8500 – 192 Gb – Registered
- Pc3-10600 – 144 Gb – Registered
- Pc3-10600 – 48 Gb – Unbuffered
Storage
- Hard Drive: None.
Storage Controllers
- Storage Controller Type: 1 X Raid – Plug-In Card – Pci Express X8
- Controller Interface Type: Serial Ata-300 / Sas 2.0
- Storage Controller Name: Smart Array P410i
- Raid Level: Raid 0, Raid 1, Raid 5, Raid 10, Raid 50
- Buffer Size: 256 Mb
Display & Graphics
- Graphics Controller Type: Integrated
- Graphics Processor: Ati Es1000
- Video Memory: 32 Mb
Networking
- Networking: Network Adapter – Pci Express X4 – Integrated
- Ethernet Ports: 4 X Gigabit Ethernet
- Ethernet Controller(S): 2 X Hp Nc382i
- Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Controller: Integrated Lights-Out 3
- Features: Wake On Lan (Wol), Acpi Support, Pxe Support
- Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
Expansion & Connectivity
- Expansion Bays Total (Free):
- 4 ( 4 ) X Hot-Swap – 2.5 Sff
- 1 ( 1 ) X Front Accessible – 5.25 Slim Line
- Expansion Slots Total (Free):
- 1 ( 1 ) X Pci Express 2.0 X16 – Full-Length, Full-Height
- 1 ( 0 ) X Pci Express 2.0 X8 – Low-Profile
- 18 ( 15 ) X Memory – Dimm 240-Pin
- 2 ( 1 ) X Processor
- Interfaces & Ports:
- 1 X Serial – Rs-232 – 9 Pin D-Sub (Db-9)
- 2 X Display / Video – Vga – 15 Pin Hd D-Sub (Hd-15) ( 1 Front, 1 Rear )
- 3 X Usb – 4 Pin Usb Type A ( 1 Front, 2 Rear )
- 4 X Network – Ethernet 10base-T/100base-Tx/1000base-T – Rj-45
- 1 X Management – Hp Ilo – Rj-45
Power Description
- Device Type: Power Supply – Hot-Plug
- Power Redundancy: Optional
- Power Redundancy Scheme: 1+1 (With Optional Power Supply)
- Installed Qty: 1
- Max Supported Qty: 2
- Voltage Required: Ac 120/230 V ( 50/60 Hz )
- Power Provided: 460 Watt
