When it comes to choosing a server for your business, there are a lot of options available in the market. One of the popular options is the HPE Proliant DL360 G9 Base Model 1X Intel Xeon 10-Core E5-2630V4 server. This server is a 1U rack server designed for small to medium-sized businesses that require high performance, reliability, and scalability. In this article, we will take a closer look at the specifications of this server and its features.
Specifications
The HPE Proliant DL360 G9 Base Model 1X Intel Xeon 10-Core E5-2630V4 server comes with the following specifications:
Processor: 1X Intel Xeon 10-Core E5-2630V4/ 2.2GHz Memory: 16GB DDR4 SDRAM Storage controller: HPE Smart Array P440AR with 2GB FBWC Drive bays: 8SFF Network interface: 1GB 4-port 331i Adapter Power supply: 1X 500W FS PS
Processor
The HPE Proliant DL360 G9 Base Model 1X Intel Xeon 10-Core E5-2630V4 server is powered by an Intel Xeon 10-Core E5-2630V4 processor. The processor has a clock speed of 2.2GHz, which is ideal for handling complex workloads. The processor also supports hyper-threading, which allows for better performance when running multiple applications simultaneously.
Memory
The server comes with 16GB DDR4 SDRAM memory, which is expandable up to 768GB. The DDR4 memory technology provides higher performance, increased reliability, and lower power consumption than its predecessor, DDR3.
Storage Controller
The server is equipped with the HPE Smart Array P440AR storage controller, which comes with 2GB Flash Backed Write Cache (FBWC). The Smart Array P440AR is a RAID controller that provides advanced storage functionality, including RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, and RAID 50. The Flash Backed Write Cache provides data protection in the event of a power failure.
Drive Bays
The server comes with eight Small Form Factor (SFF) drive bays, which are designed to accommodate 2.5-inch hard drives or solid-state drives (SSDs). The eight drive bays provide enough storage capacity to support the most demanding workloads.
Network Interface
The server comes with a 1GB 4-port 331i Adapter, which provides network connectivity to the server. The adapter supports Ethernet, Fast Ethernet, and Gigabit Ethernet. The four ports allow for better network redundancy and load balancing.
Power Supply
The server is powered by a single 500W FS (Flex Slot) power supply. The FS power supply is a hot-swappable, energy-efficient power supply that can be easily replaced without having to power down the server.
Features
The HPE Proliant DL360 G9 Base Model 1X Intel Xeon 10-Core E5-2630V4 server comes with a variety of features that make it an ideal choice for small to medium-sized businesses.
Scalability
The server is designed to be scalable, which means that it can be easily upgraded to meet the changing needs of your business. The server comes with several expansion slots, including three PCIe 3.0 slots, one PCIe 2.0 slot, and one dedicated internal storage slot.
Summary, The HPE Proliant DL360 G9 Base Model 1X Intel Xeon 10-Core E5-2630V4 server is a high-performance 1U rack server designed for small to medium-sized businesses. It comes with an Intel Xeon 10-Core E5-2630V4 processor, 16GB DDR4 SDRAM memory, HPE Smart Array P440AR storage controller with 2GB Flash Backed Write Cache, eight Small Form Factor (SFF) drive bays, a 1GB 4-port 331i Adapter for network connectivity, and a 500W FS (Flex Slot) power supply. The server is designed to be scalable and comes with features such as HPE’s Integrated Lights Out (iLO) management system for remote management.
General Information
- Manufacturer : Hewlett Packard Enterprise(HPE)
- Manufacturer Part Number : 818208-B21
- Type: Server
- Sub-Type: Proliant DL360
- Product Name: Proliant Dl360 G9 – 1u Rack Mountable Server (Base Model)
Processor & Chipset
- CPU : Intel Xeon E5-2630v4 / 2.2 GHz
- Max Turbo Speed : 3.1 GHz
- Number Of Cores : 10-Core
- Cpu Qty : 1
- Max Cpu Qty : 2
- Cpu Upgradability : Upgradable
- Processor Main Features : Hyper-Threading Technology, Intel Turbo Boost Technology 2
- Cpu Socket : Lga2011-V3 Socket
Cache Memory
- Installed Size : 25 Mb
- Cache Per Processor : 25 Mb
Memory
- Installed Size : 16 Gb / 768 Gb (Max)
- Technology : Ddr4 Sdram – Advanced Ecc
- Memory Speed : 2133 Mhz
- Memory Specification Compliance : Pc4-19200
- Form Factor : Dimm 288-Pin
- Features : Registered, Online Spare Memory, Quad Channel Memory Architecture, Hp Smartmemory
- Configuration Features : 1 X 16 Gb
- Ram Supported : Pc4-19200 – 3 Tb – Load-Reduced ¦ Pc4-17000 – 768 Gb – Registered ¦ 128 Gb – Non-Volatile
Storage
- Hard Drive : None
- Optical Drive : None
- Storage Controllers:
- Type : 1 X Raid – Pcie 3.0 X8
- Controller Interface Type : Sata 6gb/S / Sas 12gb/S
- Storage Controller Name : Smart Array P440ar With 2gb Fbwc
- Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60, Raid 1 Adm, Raid 10 Adm
- Buffer Size : 2 Gb
Display & Graphics Controllers
- Ggraphics Processor : Matrox G200
- Video Interfaces : Vga
Network & Communication
- Ethernet Ports : 4 X Gigabit Ethernet
- Ethernet Controller : Hp 331i
- Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Controller : Integrated Lights-Out 4
- Features : Wake On Lan (Wol), Pxe Support
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Power Description
- Device Type : Power Supply – Hot-Plug
- Power Redundancy : Optional
- Power Redundancy Scheme : 1+1 (With Optional Power Supply)
- Installed Qty : 1
- Max Supported Qty : 2
- Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
- Power Provided : 500 Watt
- 80 Plus Certification : 80 Plus Platinum.
