Description
High Capacity Storage for Demanding
“High Capacity Storage for Demanding Applications” refers to the ability of the HPE 857642-002 hard drive to provide a large amount of storage space for applications that require a lot of data to be stored and accessed quickly. This hard drive has a capacity of 10TB, which is significantly more than the storage space typically found in standard hard drives. This makes it ideal for use in data centers, high-performance computing environments, and other applications that require large amounts of storage and fast data access. The SAS interface of 12 Gbps and 7.2K RPM also helps to increase the performance of the drive, making it suitable for demanding applications that require quick access to large amounts of data.
SAS Hard Drive for Enterprise Use
“10TB SAS Hard Drive for Enterprise Use” refers to the HPE 857642-002 hard drive’s capacity of 10 terabytes and its SAS interface, making it suitable for use in enterprise-level environments. SAS (Serial Attached SCSI) is a high-performance data storage interface that is commonly used in enterprise storage systems, data centers, and other demanding applications. The 10TB of storage space allows for the storage of large amounts of data, making it ideal for use in environments where large amounts of data need to be stored and accessed quickly. This drive also has a 12 Gbps SAS interface which is faster than traditional SAS interface, this enables the drive to handle more data at a faster rate, and the 7.2k RPM further increases the performance.
SAS Interface for Fast Data Transfer
The SAS Interface for Fast Data Transfer (SAS IFD) is a high-speed data transfer technology that allows for the transfer of large amounts of data between SAS and other systems. It uses a parallel data transfer mechanism that can transfer data at speeds up to several GB per second. This allows for faster data transfer and improved performance when working with large data sets. The SAS IFD is supported on various platforms, including Windows, Linux, and UNIX.
7.2K RPM for Improved Performance
A hard drive with a rotational speed of 7200 RPM (revolutions per minute) is faster than a hard drive with a lower RPM. This is because the faster a hard drive spins, the faster it can access the data stored on it. In other words, when a hard drive’s platters spin at a faster rate, the read/write head can access data more quickly. Because of this, a 7200 RPM hard drive will typically have better performance (i.e. faster data access) than a slower 5400 RPM hard drive, which is the standard speed for most laptop hard drives.
Product Overview
- Manufacturer Name: HPE
- MPN: 857642-002-LP
- Type: Internal Hard Drive
- HDD Type: SAS-12GBPS
- SKU: 857642-002-LP
- Option Part Number: 857646-B21
- Spare Part Number: 857966-001
- Model Number: MB010000JWAYK
Technical Data
- Capacity: 10 TB
- Form Factor: 3.5 inch
- Bytes per Sector: 512
- Plug Type: Hot Pluggable
- Format Type: 512e
- Carrier Type: Low Profile Carrier (LPC)
- Workload Type: Midline
- Features: Advanced format 512e, Digitally Signed Firmware (DS)
Performance
- Rotational Speed: 7200 RPM
- Transfer Rate Synchronous (Max): 12Gb/sec
- Single Track Seek Time: 0.22 MS
- OD Media Rate, Max Sequential Throughput (MiB/s): 235
- 128Kib Random Rd (IOPs): 105
- 128Kib Random 70% RD/ 30% WT (IOPs): 110
- 128Kib Random 50% RD/ 50% WT (IOPs): 115
Environmental Parameters
- Min Operating Temperature: 50 °F (10°C)
- Max Operating Temperature: 95 °F (35°C)
Power Consumption
- Idle Time: 2.60 Watt
- Sequential Read: 4.40 Watt
- Sequential Write: 3.90 Watt
- Random Read/Write: 3.60 Watt
Dimension and Weight
- Width : 4 Inch
- Depth : 5.8 Inch
- Height : 1 Inch
- Weight : 1.52 Lbs
Compatibility Information
- HPE Apollo Series: 4200 Gen9 for Google (3.5 inch)
- HPE ProLiant DL Series: DL20 Gen10 (3.5 inch), DL20 Gen10 Entry (3.5 inch), DL20 Gen10 Performance (3.5 inch), DL20 Gen10 solution (3.5 inch)
- HPE ProLiant ML Series: ML110 Gen10 (3.5 inch), ML110 Gen10 Entry (3.5 inch), ML110 Gen10 Performance (3.5 inch), ML110 Gen10 Solution (3.5 inch), ML30 Gen10 (3.5 inch), ML30 Gen10 Entry (3.5 inch), ML30 Gen10 Performance (3.5 inch), ML30 Gen10 Solution (3.5 inch), ML350 Gen10 (3.5 inch), ML350 Gen10 Base (3.5 inch), ML350 Gen10 Entry (3.5 inch), ML350 Gen10 High Performance (3.5 inch), ML350 Gen10 Performance (3.5 inch), ML350 Gen10 SMB (3.5 inch), ML350 Gen10 Solution (3.5 inch), ML350 Gen10 Special Server (3.5 inch), ML350 Gen10 Sub-Entry (3.5 inch)
- HPE ProLiant XL Series: XL190r Gen9 (3.5 inch)
