Description
Product Overview
The HPE 857967-001 is a 10TB, 7.2K RPM, LFF (Large Form Factor) SATA-6GBPS SC Midline Hard Drive. This drive is designed for use in enterprise-level storage systems and servers, and is ideal for applications that require high capacity and reliable performance. The drive features a 3.5-inch form factor and a 6 Gb/s SATA interface, making it compatible with a wide range of hardware. The 10TB capacity of the drive provides ample storage space for large data sets and files, while the 7.2K RPM spindle speed ensures fast data access and transfer speeds. This drive is built to meet the demands of high-performance, high-availability storage environments.
Capacity
The HPE 857967-001 hard drive has a capacity of 10 terabytes (TB). This is a large amount of storage space that can be used to store large amounts of data, such as videos, music, images, and documents. This drive can be used for data backup, archiving, and storage of large databases and files. With 10TB of capacity, this drive can store up to 2,000 full-length movies, 2.5 million MP3 files, or up to 20 million digital photos. The capacity of this drive makes it suitable for use in a wide range of storage applications, including enterprise-level storage systems, data centers, and servers.
Installation and setup
Installing and setting up the HPE 857967-001 hard drive is a straightforward process. Before installing the drive, ensure that the system or server it will be installed in is compatible with the drive’s specifications, including its form factor and interface. Once compatibility has been confirmed, follow these steps to install the drive:
- Power down the system and unplug all cables.
- Open the system or server’s case and locate the drive bay where the new drive will be installed.
- Carefully slide the new drive into the bay, making sure that it is properly aligned and securely connected to the system’s SATA interface.
- Close the system’s case and reconnect all cables.
- Power on the system and boot into the operating system.
- The operating system should automatically detect the new drive.
- Format the drive, create partitions and assign it a drive letter to start using it.
It is also important to note that depending on the system it is being installed, a firmware update may be needed to support the drive, check with the vendor documentation or website before proceeding with the installation.
Product Information 857967-001:
Manufacturer Name: HPE
MPN: 857967-001
Type: Hard Drive – Hot-Swap
HDD Type: SATA-6GBPS
SKU: 857967-001
Option Part Number: 857648-B21
Model Number: MB010000GWAYN
Assembly Number: 857643-002
Technical Information 857967-001
Capacity: 10 TB
Form Factor: 3.5 inch LFF
Interface: SATA 6GBPS
Bytes per Sector: 512
Drive Technology (Fill): Helium
Plug Type: Hot Plug
Format Type: 512E
Carrier Type: Smart Carrier (SC)
Workload: Midline
Features: Advanced format 512E, Digitally Signed Firmware
Bundled with: HPE SmartDrive Carrier
Performance
Rotational Speed: 7200 RPM
Transfer Rate Synchronous (Max): 6 GB/Sec
Single Track Seek Time: 0.22 MS
Average Seek Time: 8.00 MS
Full Stroke Seek Time: 16.00 MS
Dimension and Weight
Width: 4 Inch
Depth: 5.8 Inch
Height: 1 Inch
Weight: 1.52 LBS
Expansion & Connectivity
Interfaces: 1 x SATA 6 GB/S – 7 Pin Serial ATA
Compatible Bay: 3.5 Inch LFF Low Profile
Environmental Parameters
Min Operating Temperature: 50 °F (10°C)
Max Operating Temperature: 95 °F (35°C)
Compatibility
HPE ProLiant DL Series: DL120 Gen9 (3.5 inch), DL120 Gen9 Entry (3.5 inch), DL180 Gen9 (3.5 inch), DL180 Gen9 Base (3.5 inch), DL180 Gen9 Entry (3.5 inch), DL180 Gen9 Storage (3.5 inch), DL20 Gen9 (3.5 inch), DL20 Gen9 Entry (3.5 inch), DL20 Gen9 Performance (3.5 inch), DL20 Gen9 Solution (3.5 inch), DL360 Gen10 (3.5 inch), DL360 Gen10 Base (3.5 inch), DL360 Gen10 Entry (3.5 inch), DL360 Gen10 High Performance (3.5 inch), DL360 Gen10 Low (3.5 inch), DL360 Gen10 Performance (3.5 inch), DL360 Gen10 Solution (3.5 inch), DL380 Gen10 (3.5 inch), DL380 Gen10 Base (3.5 inch), DL380 Gen10 Entry (3.5 inch), DL380 Gen10 High Performance (3.5 inch), DL380 Gen10 Performance (3.5 inch), DL380 Gen10 Solution (3.5 inch), DL385 Gen10 (3.5 inch), DL385 Gen10 Base (3.5 inch), DL385 Gen10 Entry (3.5 inch), DL385 Gen10 High-Performance (3.5 inch), DL385 Gen10 Performance (3.5 inch), DL385 Gen10 Solution (3.5 inch), DL388 Gen9 (3.5 inch), DL388 Gen9 Base (3.5 inch), DL60 Gen9 (3.5 inch), DL60 Gen9 Base (3.5 inch), DL60 Gen9 Entry (3.5 inch), DL80 Gen9 (3.5 inch), DL80 Gen9 Base (3.5 inch), DL80 Gen9 Entry (3.5 inch) Servers
HPE ProLiant ML Series: ML150 Gen9 (3.5 inch), ML150 Gen9 Base (3.5 inch), ML150 Gen9 Entry (3.5 inch), ML150 Gen9 Performance (3.5 inch), ML30 Gen9 Entry (3.5 inch), ML30 Gen9 Solution (3.5 inch) Servers
HPE StoreEasy 1450
