HPE JD119B ProCurve X120: A Comprehensive Guide to Single-mode Transceiver
In the rapidly evolving landscape of networking technologies, the HPE JD119B ProCurve X120 Transceiver Module stands out as a key component, providing seamless connectivity solutions for data transfer. In this comprehensive guide, we delve into the intricate details of this transceiver module, exploring its features, specifications, and applications.
Understanding the Basics
The HPE JD119B ProCurve X120 is a small form-factor pluggable (SFP) transceiver module designed for high-performance networking applications. Specifically, it operates at a speed of 1 Gigabyte Per Second (GBPS) and utilizes the 1000Base-LX standard for data transmission.
Key Components
- Speed: 1 GBPSThe module operates at a speed of 1 GBPS, making it suitable for various networking requirements, from small-scale office setups to large enterprise environments.
- Fiber Type: Single-modeThe use of single-mode fiber ensures efficient data transmission over longer distances with minimal signal loss, making it ideal for extended network infrastructures.
- Transmission Distance: 10kmThe module supports a transmission distance of 10 kilometers, offering flexibility in network design and enabling connectivity over considerable distances.
- Wavelength: 1310nmThe 1310nm wavelength is employed for data transmission, contributing to the module’s reliability and stability in diverse networking environments.
- Duplex LC ConnectorThe inclusion of a duplex LC connector allows for bidirectional communication, enhancing the module’s versatility in network configurations.
Applications and Use CasesVersatility in Networking Environments
The HPE JD119B ProCurve X120 Transceiver Module finds applications in various networking scenarios due to its adaptable specifications.
- Enterprise NetworksIn enterprise environments, where high-speed and reliable data transmission is paramount, the HPE JD119B plays a crucial role in connecting switches and routers, ensuring seamless communication across the network.
- Data CentersData centers require robust networking solutions to handle the vast amounts of data generated and processed daily. The HPE JD119B’s 1 GBPS speed, coupled with its 10km transmission distance, makes it well-suited for interconnecting servers and storage devices within the data center.
- Telecommunication NetworksTelecommunication networks often span extensive geographical areas. The single-mode fiber and 10km transmission capability of the HPE JD119B make it an ideal choice for establishing reliable connections in telecommunications infrastructure.
Technical Specifications of small form-factor Transceiver In-Depth Technical Analysis
- Form Factor: SFP (Small Form-Factor Pluggable)The small form-factor pluggable design is a standardized specification for transceiver modules, ensuring interoperability across various networking devices.
- Protocol: 1000Base-LXThe 1000Base-LX protocol defines the standards for gigabit Ethernet over fiber-optic connections, offering a reliable and high-speed data transmission solution.
- Wavelength Range: 1310nmThe 1310nm wavelength falls within the range of commonly used wavelengths for optical communication. This specific wavelength enhances the module’s compatibility with other networking components.
- Duplex: Full DuplexThe full-duplex communication mode allows data to be transmitted and received simultaneously, maximizing the efficiency of data transfer.
- Connector Type: LC DuplexThe LC duplex connector is a widely adopted standard in networking, providing a reliable and compact interface for fiber-optic connections.
- Transmission Distance: 10kmThe 10km transmission distance accommodates a variety of networking setups, from local area networks (LANs) to broader metropolitan area networks (MANs).
Advantages and Benefits
- ReliabilityThe HPE JD119B ProCurve X120 is built with reliability in mind, ensuring consistent and stable performance in diverse networking environments.
- High-Speed Data Transfer With a speed of 1 GBPS, this transceiver module facilitates swift and efficient data transfer, meeting the demands of modern networking applications.
- Flexibility in Network DesignThe 10km transmission distance and single-mode fiber support provide flexibility in designing networks, enabling connectivity over extended distances.
- Interoperability with HPE DevicesThe module’s seamless compatibility with other HPE networking equipment simplifies integration processes and enhances overall system compatibility.
Advanced Technology
The HPE JD119B ProCurve X120 doesn’t just stop at providing high-speed data transfer and long-range capabilities. It incorporates advanced technology to meet the demands of modern networking:
- Hot-Pluggable Design: The hot-pluggable nature of the module allows for easy and convenient installation without the need to power down the entire network. This feature contributes to network flexibility and minimizes downtime during installation or upgrades.
- Digital Diagnostic Monitoring: The inclusion of digital diagnostic monitoring capabilities provides administrators with valuable insights into the performance of the module. Real-time data on parameters such as temperature, voltage, and signal strength can be monitored, allowing for proactive maintenance and troubleshooting.
- Low Power Consumption: Efficiency is a key consideration in contemporary networking solutions, and the JD119B ProCurve X120 addresses this with its low power consumption. This not only contributes to energy savings but also reduces heat generation, promoting a more sustainable and reliable networking infrastructure.
- Compatibility with HPE Devices: Designed by Hewlett Packard Enterprise (HPE), this transceiver module is optimized for seamless integration with HPE networking equipment. This ensures a high level of compatibility and performance when used within an HPE-centric network environment.
Product Information about the HPE JD119B
- Manufacturer HPE
- Model Number or SKU# JD119B
- Product Name: Transceiver Module
- Product Type: GBIC-SFP Transceiver
Technical Information SFP Transceiver
- Enclosure Type Plug-in module
- Cabling Type 1000Base-LX
- Data Transfer Rate 1 Gbps
- Data Link Protocol Gigabit Ethernet
In short, the HPE JD119B ProCurve X120 1 Gigabyte Per Second (GBPS) 1000Base-LX Single-mode Fiber 10km 1310nm Duplex LC Connector Small Form-Factor Pluggable Transceiver Module stands as a reliable and high-performance solution for modern networking needs. Its combination of high-speed data transfer, long-distance capabilities, and versatile design make it a valuable asset for organizations seeking to enhance their network infrastructure.
By understanding the technical specifications, benefits, and installation procedures outlined in this comprehensive guide, network administrators can make informed decisions about integrating the ProCurve X120 into their networks. Whether used in data centers, enterprise environments, or other networking scenarios, the ProCurve X120 is poised to deliver efficient and reliable performance, contributing to the overall success of the organization’s digital operations.
