Description
Performance and Scalability
The JG301-61301 HPE 3600-24-PoE+ V2 Ei Switch is a high-performance and scalable switch designed for small and medium-sized businesses. This switch has 24 PoE+ ports, 2 SFP uplink ports, and 2 Gigabit Ethernet uplink ports. It supports both standard and enhanced image (EI) firmware, which enhances the switch’s capabilities and provides more advanced features.
Performance-wise, this switch has a forwarding rate of up to 35.7 million packets per second, making it ideal for high-bandwidth applications. Additionally, it supports Quality of Service (QoS) and Traffic Prioritization, which allows for efficient use of network resources and ensures that mission-critical applications receive the necessary bandwidth.
In terms of scalability, this switch is designed for network growth. It supports multiple VLANs, allowing for segmentation of the network and reducing network congestion. Additionally, it has the ability to stack multiple switches together, increasing the number of available ports and providing a scalable solution for growing networks.
Management and Monitoring
The JG301-61301 HPE 3600-24-PoE+ V2 Ei Switch is a managed switch designed for use in medium to large-sized enterprises. The switch is capable of providing both data and power over Ethernet (PoE+) to connected devices, making it a versatile and cost-effective solution for businesses looking to deploy PoE-enabled devices.
The switch management and monitoring features of the JG301-61301 HPE 3600-24-PoE+ V2 Ei Switch include:
- Web-based Management: The switch can be managed and configured through a web-based interface, providing a user-friendly and convenient way to manage the switch from any location with an internet connection.
- Command Line Interface (CLI): The switch also offers a command-line interface for advanced users and administrators who prefer to manage the switch through a command-line interface.
- SNMP Support: The switch supports Simple Network Management Protocol (SNMP) for monitoring and management, allowing administrators to remotely monitor the switch’s performance and receive alerts in case of any issues.
- Port Mirroring: The switch supports port mirroring, allowing administrators to monitor network traffic by copying traffic from one port to another for analysis and troubleshooting purposes.
- Link Aggregation: The switch supports link aggregation, allowing administrators to bundle multiple physical connections into a single logical connection for increased bandwidth and redundancy.
Power and Environmental
The JG301-61301 HPE 3600-24-PoE+ V2 Ei Switch is a network switch that provides Power over Ethernet (PoE+) capabilities, allowing users to power and connect devices such as phones, cameras, and wireless access points through a single Ethernet cable.
In terms of power, the switch supports up to 375 watts of PoE budget, with a maximum of 30 watts per port. This allows for the powering of high-powered devices, such as pan-tilt-zoom cameras.
The environmental aspect of the switch involves its operational temperature range, which is from 0 to 50°C (32 to 122°F), and its relative humidity range of 10 to 90% non-condensing. This allows for the switch to be used in a variety of environments, from data centers to harsh industrial settings. The switch also features advanced energy-saving features, such as cable length detection and automatic power reduction for unused ports, helping to reduce energy costs and lower the environmental impact of the device.
DETAIL DESCRIPTION
- Manufacturer: HPE
- Part Number or SKU# JG301-61301
- Device Type : Managed Switch – 24 Ports
Technical Information
- Ports : 24 X 10/100 (Poe+) + 4 X Gigabit Sfp + 2 X Combo 1000base-T
- Power Over Ethernet (Poe) : Poe+
- Poe Budget : 720 W
- Performance : Throughput : 9.5 Mpps ¦ Routing/Switching Capacity : 12.8 Gbps
- Capacity : Ipv4 Routing Table Entries : 12000
- Mac Address Table Size : 32000 Entries
- Jumbo Frame Support : 9216 Bytes
Protocol System & Features
- Routing Protocol : Ospf, Rip, Is-Is, Bgp, Igmpv2, Igmp, Pim-Sm, Pim-Dm, Igmpv3, Ospfv3, Pim-Ssm, Static Ipv4 Routing, Static Ipv6 Routing, Mld, Bgp-4+, Bidirectional Forwarding Detection (Bfd)
- Remote Management Protocol : Snmp 1, Telnet, Snmp 3, Snmp 2c, Https, Ssh-2
- Encryption Algorithm : Ssl
- Authentication Method : Radius, Hwtacacs
- Features : Dhcp Support, Arp Support, Syslog Support, Weighted Round Robin (Wrr) Queuing, Weighted Fair Queuing (Wfq), Weighted Random Early Detection (Wred), Sflow, Spanning Tree Protocol (Stp) Support, Rapid Spanning Tree Protocol (Rstp) Support, Virtual Route Redundancy Protocol (Vrrp) Support, Multiple Spanning Tree Protocol (Mstp) Support, Quality Of Service (Qos), Committed Access Rate (Car), Device Link Detection Protocol (Dldp) Support, Rapid Ring Protection Protocol (Rrpp) Support, Equal-Cost Multipath (Ecmp), Endpoint Admission Defense (Ead), Stp Root Guard, Lldp Support, Port Security, Dhcp Protection, 2mb Packet Buffer, Port Isolation, Non Blocking Ports, Strict Priority (Sp), Generic Attribute Registration Protocol (Garp), Intelligent Resilient Framework Technology (Irf), Multicast Source Discovery Protocol (Msdp)
- Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3i, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3af, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ac, Ieee 802.1s, Ieee 802.1v, Ieee 802.1ab (Lldp), Ieee 802.3at
Mamory
- Ram : 256 Mb – Sdram
- Flash Memory : 128 Mb
Expansion / Connectivity
- Interfaces : 1 X Serial (Console) – Rj-45 ¦ 24 X 100base-Tx – Rj-45 – Poe+ ¦ 4 X Gigabit Lan – Sfp ¦ 2 X 1000base-T
