Description
Product Details of the HPE JZ332-61001
The JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4
802.11ax External Antennas Unified Campus Access Point is a high-performance
wireless access point designed for use in large campuses, such as universities,
hospitals, and large businesses. In this article, we will discuss the features
and capabilities of the JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4
802.11ax External Antennas Unified Campus Access Point.
Design and Build
The JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4
802.11ax External Antennas Unified Campus Access Point is a well-built device
that is designed to withstand harsh environments. The access point is built
with external antennas that allow for a wider coverage range, providing access
to wireless networks from a greater distance. The device is also designed with
a dual radio that supports both 2.4 GHz and 5 GHz frequencies, making it
compatible with a wide range of devices.
The JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4
802.11ax External Antennas Unified Campus Access Point is also designed with a
4×4:4 configuration, which allows for faster speeds and more reliable
connections. This means that the access point is capable of supporting up to 4
simultaneous streams of data, making it ideal for large campuses that have a
high demand for wireless connectivity.
Features and Capabilities
The JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4 802.11ax External Antennas Unified Campus Access Point comes with a range of features and capabilities that make it a powerful tool for managing wireless networks in large campuses. One of the key features of the access point is its ability to support the latest 802.11ax standard, which provides faster speeds and more reliable connections than previous wireless standards.
The access point also comes with a unified access point feature, which allows for easy management of wireless networks across multiple devices. This means that administrators can manage the access point and all of the devices connected to it from a single location, simplifying network management and improving network security.
The JZ332-61001 HPE Aruba Ap-534 (Us) Dual Radio 4×4:4 802.11ax External Antennas Unified Campus Access Point also comes with advanced security features that help to protect the network from unauthorized access. The access point supports WPA3, which provides stronger encryption and authentication, making it more difficult for hackers to access the network. The access point also comes with a range of other security features, including firewall protection and access control lists.
Once the access point is installed, administrators can use the Aruba Central platform to configure and manage the device. The Aruba Central platform provides a range of tools for managing wireless networks, including the ability to create and manage user accounts, monitor network traffic, and configure security settings.
General Information about the HPE JZ332-61001
- Manufacturer: HPE
- Part Number or SKU# JZ332-61001
- Product Type: 2.5GBPS Access Point
Main Features
- Form Factor : In-Ceiling
- Connectivity Technology : Wireless
- Data Transfer Rate : 2.4 GBPS
- Line Coding Format : Cck, 64 Qam, 256 Qam, Bpsk, Qpsk, 16 Qam, Ofdm, 1024 Qam, Ofdma
- Data Link Protocol : IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax
- Spread Spectrum Method : Ofdm, Dsss, Ofdma
- Frequency Band : 2.4 GHz, 5 GHz
- Performance : Maximum Data Rate (2.4 GHz): 1150 Mbps ¦ Maximum Data Rate (5 GHz): 2.4 GBPS ¦ Aggregate Bandwidth: 3.55 GBPS
- Capacity : Wireless Clients Per Wi-Fi Radio: 1024 ¦ Ofdma Units: 37 ¦ Bssids Per Radio: 16
- Status Indicators : System, Status
- Trusted Platform Module (Tpm), Lacp Support, Adaptive Radio Management (Arm), Maximum Ratio Combining (Mrc), Low Density Parity Check (Ldpc), Transmit Beam-Forming (Txbf) Ready, Direct Sequence Spread Spectrum (Dsss), Cyclic Delay Diversity (Cdd), Space Time Blocking Code (Stbc), Advanced Cellular Coexistence (Acc), Clientmatch, Cyclic Shift Diversity (Csd), Apprf Technology, Mu-Mimo Technology, Packet Aggregation A-Mpdu, Packet Aggregation A-Msdu, Air Monitor (Am), Intelligent Power Monitoring (Ipm), Dynamic Frequency Selection (Dfs), High-Throughput (Ht) Support, 4×4 Mu-Mimo Technology, Orthogonal Frequency Division Multiplexing (Ofdm), Aruba Airmatch, Spectrum Analyzer, Very High Throughput (Vht) Support, Orthogonal Frequency Division Multiple Access (Ofdma), Unified Ap Support, Custom Deep-Sleep Mode, High Efficiency (He) Support, Target Wait Time (Twt)
- Encryption Algorithm : Wpa, Wpa2, Wpa3
- Compliant Standards : IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax
Antenna
- Antenna : External Detachable
- Antenna Qty : 4
Expansion / Connectivity
- 1 X Hpe Smart Rate – Rj-45
- 1 X Usb 2.0 – Type A
- 4 X Antenna – Rp-Sma X 4
