Description
Performance Benchmarks
Performance benchmarks are tests that are used to measure the performance of a storage device like the HPE P04560-H21 SATA 6GBPS 480GB 2.5-inch Read Intensive Internal solid-state drive. These benchmarks can help users understand the speed and overall performance of the drive, allowing them to make more informed decisions about whether the drive is right for their needs.
There are several performance benchmarks that can be used to evaluate the HPE P04560-H21 SSD, including:
- Sequential Read and Write: This benchmark tests the speed of reading and writing large, contiguous blocks of data. Higher sequential read and write speeds indicate that the SSD can transfer data faster.
- Random Read and Write: This benchmark measures the speed of reading and writing small, randomly placed blocks of data. This is important for applications that require fast access to a large number of small files, such as databases.
- 4K Read and Write: This benchmark tests the speed of reading and writing small 4KB blocks of data. This is important for applications that require fast access to small files, such as operating systems.
- IOPS (Input/Output Operations Per Second): This benchmark measures the number of read and write operations that the drive can perform per second. Higher IOPS indicate that the SSD can handle a greater number of requests at once.
- Latency: This benchmark measures the time it takes for the SSD to respond to a request. Lower latency indicates that the drive is more responsive and can handle requests more quickly.
Performance benchmarks can be conducted using various tools and software, such as CrystalDiskMark, ATTO Disk Benchmark, and AS SSD Benchmark. By evaluating the results of these benchmarks, users can gain a better understanding of how the HPE P04560-H21 SSD performs in different scenarios and whether it meets their performance requirements.
Usage Scenarios
The HPE P04560-H21 SATA 6GBPS 480GB 2.5-inch Read Intensive Internal solid-state drive is designed for read-intensive workloads and is optimized for read-heavy applications. Here are some common usage scenarios for this SSD:
- Web servers: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in web servers that have high read workloads, such as those serving static web pages, images, and videos.
- Media streaming: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in media streaming servers that require fast read speeds to stream high-quality videos and music.
- Data warehousing: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in data warehouses that require fast read access to large amounts of data.
- Content delivery networks: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in content delivery networks that serve frequently accessed content, such as images, videos, and audio files.
- Online transaction processing (OLTP): The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in OLTP applications that require fast read access to small amounts of data, such as e-commerce websites.
- Virtual desktop infrastructure (VDI): The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in VDI environments that require fast read access to virtual desktop images and user profiles.
- Big data analytics: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in big data analytics environments that require fast read access to large datasets.
- Data backup and recovery: The HPE P04560-H21 SATA 6GBPS 480GB SSD can be used in backup and recovery systems that require fast read access to backup data.
Compatibility with Other Systems
The HPE P04560-H21 SATA 6GBPS 480GB 2.5-inch Read Intensive Internal solid-state drive is designed to be compatible with a wide range of systems that support the SATA III 6Gbps interface. This includes desktop computers, laptops, workstations, and servers that have a standard 2.5-inch drive bay.
The HPE P04560-H21 SSD uses a standard SATA interface, which means it can replace traditional spinning hard drives in most systems with a SATA interface, without any need for additional hardware or software. Additionally, the HPE P04560-H21 SSD supports the hot-plug feature, allowing you to replace it while the system is running.
To ensure compatibility, it is important to verify that your system supports the SATA III 6Gbps interface and has a 2.5-inch drive bay available. It is also recommended to check the documentation of your system to ensure that it supports the maximum capacity of the HPE P04560-H21 SSD.
In addition to the hardware compatibility, the HPE P04560-H21 SSD is also compatible with a wide range of operating systems, including Windows, Linux, and VMware. The drive supports a variety of file systems, such as NTFS, FAT32, and EXT4.
Product Information
- Manufacture: HPE
- MPN: P04560-H21
- Type: Solid State Drive – Hot-Swap
- SSD Type: SATA 6GBPS
- SKU: P04560-H21
- Spare Part Number: P05320-001
- Model Number: VK000480GWSRR
- Assembly Number: P02760-002
Technical Information
- Capacity: 480 GB
- Form Factor: 2.5 inch SFF
- Interface: SATA 6GBPS
- Workload Type: Read Intensive
- Carrier Type: Smart Carrier (SC)
- NAND Flash Memory Type: Triple-level cell (TLC)
- Connection Type: Single Port
- Plug Type: Hot Plug
- Features: Digitally Signed Firmware
- Bundled with: HPE Smart Drive Carrier
Dimensions & Weight
- Height: 0.63 Inch
- Width: 3.10 Inch
- Depth: 5.45 Inch
- Weight: 1.50 Lbs
Power
- Idle Time: 1.12 Watt
- Random Read: 2.29 Watt
- Random Write: 2.29 Watt
- Sequential Read: 1.89 Watt
- Sequential Write: 2.50 Watt
- Random R/W: 2.29 Watt
- Max Power Requirement: 3.00 Watt
Compatibility
- HPE Apollo Series: 4200 Gen9 for Google (2.5inch)
- HPE ProLiant BL Series: BL660c Gen9 (2.5inch), DL180 Gen10 (2.5inch)
- HPE ProLiant DL Series: DL180 Gen10 Entry (2.5inch), DL180 Gen10 SMB (2.5inch), DL20 Gen10 (2.5inch), DL20 Gen10 Entry (2.5inch), DL20 Gen10 Performance (2.5inch), DL20 Gen10 solution (2.5inch), DL325 Gen10 Base (2.5inch), DL325 Gen10 Solution (2.5inch), DL360 Gen9 (2.5inch), DL360 Gen9 CMS (2.5inch), DL360 Gen9 Performance (2.5inch), DL360 Gen9 Special Server (2.5inch), DL380 Gen10 (2.5inch), DL380 Gen10 All Flash Server for Datera (2.5inch), DL380 Gen10 Base (2.5inch), DL380 Gen10 Entry (2.5inch), DL380 Gen10 Entry SMB (2.5inch), DL380 Gen10 for Cohesity DataPlatform (2.5inch),
- DL380 Gen10 High Performance (2.5inch), DL380 Gen10 Hybrid Server for Datera (2.5inch), DL380 Gen10 Network Choice (2.5inch), DL380 Gen10 Network Choice for CTERA (2.5inch), DL380 Gen10 Performance (2.5inch), DL380 Gen10 Server for CTERA (2.5inch), DL380 Gen10 SMB (2.5inch), DL380 Gen10 SMB Networking Choice (2.5inch), DL380 Gen10 Solution (2.5inch), DL380 Gen9 Scale-up SAP HANA Tailored Datacenter Integration Compute Block (2.5inch), DL380 Gen9 Special (2.5inch), DL385 Gen10 Plus (2.5inch), DL385 Gen10 Plus Entry (2.5inch), DL580 Gen9 (2.5inch), DL580 Gen9 Base (2.5inch), DL580 Gen9 Database (2.5inch), DL580 Gen9 High Performance (2.5inch), DL580 Gen9 SAP HANA Scale-out Base Configuration (2.5inch), DL580 Gen9 SAP HANA Scale-up Base Configuration (2.5inch)
- HPE ProLiant ML Series: ML30 Gen10 (2.5inch), ML30 Gen10 Entry (2.5inch), ML30 Gen10 Performance (2.5inch), ML30 Gen10 Solution (2.5inch), ML350 Gen10 (2.5inch), ML350 Gen10 Base (2.5inch), ML350 Gen10 Entry (2.5inch), ML350 Gen10 High Performance (2.5inch), ML350 Gen10 Performance (2.5inch), ML350 Gen10 SMB (2.5inch), ML350 Gen10 Solution (2.5inch), ML350 Gen10 Special Server (2.5inch), ML350 Gen10 Sub-Entry (2.5inch), WS460c Gen9 (2.5inch), WS460c Gen9 Graphics (2.5inch), WS460c Gen9 Graphics Expansion (2.5inch), XL270d Gen9 (2.5inch)
- HPE Synergy Series 680 Gen9 4S-EX Base Compute Module (2.5inch), 680 Gen9 4S-EX Compute Module (2.5inch), 680 Gen9 4S-EX Performance Compute Module (2.5inch)
