Description
Key Features and Specifications
The HPE 64GB 2933MHZ DDR4 RAM P06190-001 is a high-performance memory module that offers several key features and specifications:
- Capacity: The module has a capacity of 64GB, which allows for large amounts of data to be stored and quickly accessed by the system.
- Speed: The module has a speed of 2933 MHz, which means it can transfer data at a rate of 2933 million times per second. This high speed improves system performance and allows for faster multitasking and data processing.
- Technology: The module uses PC4-23400 memory technology, which is a type of DDR4 SDRAM (Double Data Rate 4 Synchronous Dynamic Random-Access Memory). DDR4 is the latest and fastest type of RAM technology currently available and it is designed to improve system performance and energy efficiency.
- Pin Out: The module has 288 pins and a CAS latency of 21. CAS latency refers to the number of clock cycles it takes for the RAM to access a specific location in memory after receiving a request. Lower CAS latency generally results in faster system performance.
- Compatibility: The module is typically used in servers, high-performance workstations, and other systems that require large amounts of memory and fast data transfer speeds. It can be used to upgrade or expand the memory of a system, allowing for more efficient multitasking and improved overall system performance.
- Brand: The module is manufactured by Hewlett Packard Enterprise (HPE) and it has a part number P06190-001.
These features and specifications make the HPE 64GB 2933MHZ DDR4 RAM P06190-001 an ideal solution for systems that require large amounts of memory and fast data transfer speeds. It is ideal for servers, high-performance workstations, and other systems that require large amounts of memory and fast data transfer speeds.
Pin Configuration and Form Factor
The HPE 64GB 2933MHZ DDR4 RAM P06190-001 memory module has a specific pin configuration and form factor that determines its compatibility with different types of systems.
- Pin Configuration: The module has 288 pins, which are used to connect the module to the memory slots on the motherboard. The pin configuration is specific to DDR4 memory technology and is not compatible with older types of memory such as DDR3.
- Form Factor: The module has a form factor of DIMM (Dual In-line Memory Module). This is a type of memory module that is commonly used in desktop computers and servers. It has a rectangular shape and is designed to fit into a slot on the motherboard. The form factor of the module is important because it determines whether it will fit into the memory slot on the motherboard.
The module is designed to fit into a 288-pin DIMM slot on the motherboard. The 288-pin DIMM is the standard form factor for DDR4 memory and it is not compatible with older DDR3 memory, which uses a different pin configuration. In order to use the HPE 64GB 2933MHZ DDR4 RAM P06190-001, you will need a system with a motherboard that has a 288-pin DIMM slot that is compatible with DDR4 memory.
It’s important to make sure that your system is compatible with the module’s pin configuration and form factor before purchasing and installing it. You can check the motherboard or computer’s manual or consult the system’s manufacturer to ensure compatibility.
Power Efficiency and Heat Dissipation
Power efficiency and heat dissipation are important factors to consider when purchasing and using a memory module such as the HPE 64GB 2933MHZ DDR4 RAM P06190-001.
- Power Efficiency: DDR4 memory technology is designed to be more power efficient than older types of memory such as DDR3. The module’s power consumption is typically lower than that of DDR3 modules, which can help to reduce the overall power usage of the system. This can be especially beneficial for systems that are running for long periods of time or in environments where power usage is a concern.
- Heat dissipation: The module generates heat as it operates, and it’s important that this heat is dissipated effectively to prevent overheating and damage to the module. The module has built-in heat dissipation features such as thermal sensors that can detect changes in temperature and adjust the module’s power usage accordingly. Additionally, the module is designed to dissipate heat efficiently through its heatsink, which helps to keep the module cool.
It’s important to make sure that the system in which the module is installed has proper ventilation to dissipate the heat generated by the module. Additionally, the module should be placed in an area with good airflow to help dissipate heat.
General Information
- Brand Name: HPE
- MPN: P06190-001
- Type: Memory (RAM)
- RAM Type: PC4-23400
- Product Name: HPE 64GB 1X64GB Quad Rank X4 DDR4-2933 Cas-21-21-21 Load Reduced Smart Memory Kit
- Product Type: Ram Module
- Option Part Number: P00926-B21
- SKU: P06190-001
- Assembly Number: P03054-091
Technical Information
- Storage Capacity: 64GB
- Memory Type: DDR4 SDRAM DIMM 288-PIN
- Number Of Modules: 1 X 64GB
- Memory Speed: 2933MHZ Pc4-23400
- Features: Quad Rank X4, Load-Reduced Dimm (Lrdimm)
- Voltage: 1.2 V
- Latency Timings: Cl21 (21-21-21)
- Upgrade Type: System Specific
Physical Characteristics
- Dimensions (W X D X H) : 8.89 X 19.81 X 1.91 Cm (3.5 X 7.8 X 0.75 In)
- Weight: 0.45 Kg (1 Lb)
Compatibility Information
- HPE ProLiant BL Series: BL460c Gen10
- HPE ProLiant DL Series: DL380 Gen10, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 High Performance, DL380 Gen10 Performance, DL380 Gen10 SMB, DL380 Gen10 Solution, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance
- HPE ProLiant ML Series: ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 High Performance, ML350 Gen10 Performance, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry
- HPE Proliant Apollo 2000 Xl170r/Xl190r/Apollo 4200/Apollo 4500 Xl450/Apollo 6500 Servers
