Description
Product overview of the HPE P10943-B21
The P10943-B21 HPE Intel Xeon 10 Core Gold 5215 is a powerful processor designed for use in high-performance computing environments. It is based on Intel’s latest technology and features 10 cores, which makes it capable of handling even the most demanding workloads.
In this article, we will take a detailed look at the specifications of this processor and explore what makes it so powerful.
Processor Specifications
The P10943-B21 HPE Intel Xeon 10 Core Gold 5215 processor has the following specifications:
- 10 cores
- 20 threads
- 2.5GHz base frequency
- 3.3GHz maximum turbo frequency
- 13.75MB cache
- 10.4GT/s UPI speed
- Socket FCLGA3647
- 14nm lithography
- 85W TDP
In the following sections, we will explain each of these specifications in detail.
Number of Cores
The P10943-B21 HPE Intel Xeon 10 Core Gold 5215 processor has 10 cores. A core is a processing unit that can execute instructions. Having more cores means that the processor can execute more instructions simultaneously, which can improve performance in applications that can take advantage of multiple cores.
Number of Threads
The processor also has 20 threads. A thread is a sequence of instructions that can be executed independently. Having more threads allows the processor to perform more tasks simultaneously, which can improve overall performance.
Base Frequency
The base frequency of the P10943-B21 HPE Intel Xeon 10 Core Gold 5215 processor is 2.5GHz. This is the frequency at which the processor operates when it is not under load. The higher the base frequency, the faster the processor can execute instructions.
Maximum Turbo Frequency
The maximum turbo frequency of the processor is 3.3GHz. This is the frequency at which the processor can operate when it is under load. The processor can dynamically adjust its frequency based on the workload, which can improve performance.
Cache
The processor has a cache size of 13.75MB. The cache is a small amount of high-speed memory that the processor uses to store frequently accessed data. Having a larger cache can improve performance because the processor can access data more quickly.
UPI Speed
The processor has a UPI (Ultra Path Interconnect) speed of 10.4GT/s. UPI is a high-speed interconnect technology that allows processors to communicate with each other. Having a faster UPI speed can improve performance in multi-processor systems.
Socket Type
The P10943-B21 HPE Intel Xeon 10 Core Gold 5215 processor is designed to be used in a socket type FCLGA3647. This is a socket type that is designed for high-performance processors.
Lithography
The processor is manufactured using a 14nm lithography process. Lithography is the process of creating the transistors and other components on the processor. A smaller lithography process can improve performance and reduce power consumption.
TDP
The TDP (Thermal Design Power) of the processor is 85W. This is the maximum amount of power that the processor is designed to consume under normal operating conditions. A lower TDP can reduce power consumption and heat generation.
In Summary,The P10943-B21 HPE Intel Xeon 10 Core Gold 5215 processor is a powerful processor designed for use in high-performance computing environments. It features 10 cores, 20 threads, a 2.5GHz base frequency, a 3.3GHz maximum turbo frequency, a 13.75MB cache, a 10.4GT/s UPI speed
General Information
- Manufacturer: Hewlett Packard Enterprise(HPE)
- MPN : P10943-B21
- Type : Processor
- SKU: P10943-B21
- Sub-Type : Intel Xeon 10 Core
Technical Information
- Processor Core : 10 Core
- Clock Speed : 2.50GHz
- Max Turbo Frequency : 3.40GHz
- Ultrapath Interconnect UPI Speed : 10.4GT/S
- No. Of UPI Links : 2
- Instruction Set : 64-Bit
- Instruction Set Extensions : Intel® Avx-512
Cache Memory Detail
- Smart Cache : 13.75MB
- Lithography : 14NM
- Max Thermal Design Power TDP : 85W
- Compatible Processor Socket : Fclga3647
Memory Specifications
- Max Memory Size Dependent On Memory Type : 1TB
- Memory Types : DDR4-2667
- Maximum Memory Speed : 2.67GHz
- Max No. Of Memory Channels : 6
- Ecc Memory Supported : Yes
