Description
Memory capacity and speed
Memory capacity refers to the amount of memory that a memory module, such as a RAM, can hold. In the case of P11445-1A1 HPE 32GB 3200Mhz Pc4-25600 Cl22 288-Pin DDR4 Reg Ecc Ram, the memory capacity is 32GB, which means that the module can hold 32 gigabytes of data.
Memory speed, on the other hand, refers to the rate at which a memory module can transfer data. In this case, the memory speed is 3200Mhz, which means that the module can transfer data at a rate of 3200 million times per second. The higher the memory speed, the faster the memory can transfer data, which can result in improved system performance.
Memory type and pin configuration
The memory type refers to the type of memory technology used in a memory module. P11445-1A1 HPE 32GB 3200Mhz Pc4-25600 Cl22 288-Pin DDR4 Reg Ecc Ram is a DDR4 memory type. DDR4 (Double Data Rate 4) is the fourth generation of DDR memory technology, and it is considered to be faster and more energy-efficient than its predecessor, DDR3.
The pin configuration refers to the arrangement of pins on a memory module. P11445-1A1 HPE 32GB 3200Mhz Pc4-25600 Cl22 288-Pin DDR4 Reg Ecc Ram has 288-pin configuration, which is the standard pin configuration for DDR4 memory modules. This is different from the older DDR3 memory modules which have a 240-pin configuration. This 288-pin configuration allows the memory module to be inserted and connected to the memory slot on the motherboard in a specific orientation.
Timing and voltage settings
Timing and voltage settings refer to the specific timing and voltage parameters that a memory module is configured to operate at. These settings are important for ensuring that the memory module is able to operate correctly and at optimal performance with the rest of the system.
Timing settings, also known as memory timings or CAS (Column Address Strobe) latencies, are a set of numbers that indicate how long it takes for the memory to access different parts of its data. Common timings include CAS Latency (CL), RAS to CAS Delay (tRCD), Row Precharge Time (tRP), and Active to Precharge Time (tRAS). Lower numbers for these timings generally indicate faster memory performance.
Voltage settings refer to the amount of voltage that the memory module requires to operate correctly. DDR4 memory typically requires 1.2V-1.4V of voltage to operate. Running the memory at a higher voltage than what is specified can cause damage to the memory and the other components in the system, while running it at a lower voltage can cause the memory to be unstable and potentially result in system crashes or data corruption.
P11445-1A1 HPE 32GB 3200Mhz Pc4-25600 Cl22 288-Pin DDR4 Reg Ecc Ram is a ECC memory type and it also has a voltage setting of 1.2V-1.4V and timing settings which are set as CL22 which means it has a CAS latency of 22 clock cycles.
General Information
- Manufacturer: HPE
- Manufacturer Part Number: P11445-1A1
- Type: Memory (RAM)
- Sub-Type: PC4-25600
- Product Name: HPE Smart Memory DDR4 32GB-Dimm 288-Pin-Registered Memory
- Product Type: Ram Module
Technical Information
- Storage Capacity: 32GB
- Memory Type: DDR4 SDRAM – Dimm 288-Pin
- Number Of Modules: 1 X 32GB
- Memory Speed: 3200mhz (PC4-25600)
- Features: Dual Rank, Registered
- Chips Organization: X8
- Error Checking: Ecc
- Voltage: 1.2v
- Latency Timings: Cl22 (22-22-22)
- Upgrade Type: System Specific
- Device Supported: Server
Compatibility Information
- Designed For: HPE Proliant Dl325 Gen10 Plus, Dl385 Gen10 Plus, Dl385 Gen10 Plus Entry
