Description
Memory capacity and speed
Memory capacity and speed are important factors to consider when purchasing RAM for a computer system. The P12403-B21 HPE 64GB 2933Mhz RAM has a memory capacity of 64GB, which is a large amount of memory that can be used for storing and running large programs and applications. This RAM is also designed to run at a speed of 2933Mhz, which is a high frequency that allows for faster access to stored data, resulting in improved performance and responsiveness of the system. The high memory capacity and speed of the P12403-B21 RAM make it well suited for use in high-performance computing systems, such as servers and workstations, as well as for demanding applications such as video editing, 3D rendering, and gaming.DDR4 SDRAM technology
DDR4 SDRAM (Double Data Rate 4 Synchronous Dynamic Random Access Memory) is a type of RAM technology that is used in modern computers. It is the fourth generation of DDR RAM, and it offers several improvements over its predecessors, DDR3 and DDR2.
One of the main improvements of DDR4 is its increased memory capacity. DDR4 can support up to 16GB per DIMM, compared to DDR3’s 8GB limit. It also has a higher clock speed, which allows for faster data transfer rates. DDR4 RAM can operate at speeds up to 3200Mhz and higher, while DDR3 is limited to a maximum of 1600Mhz.
Another improvement of DDR4 is its improved power efficiency. DDR4 uses less power than DDR3, which helps to reduce power consumption and heat generation, which can be beneficial for high-performance computing systems.
DDR4 also uses a 288-pin connector, which is different from DDR3’s 240-pin connector, and it is not compatible with DDR3-based motherboards.
The P12403-B21 HPE 64GB 2933Mhz RAM is based on DDR4 SDRAM technology, so it offers the benefits of increased memory capacity, faster data transfer rates, and improved power efficiency.
288-pin form factor
The 288-pin form factor is the physical layout of the connectors on a DDR4 memory module. The 288-pin form factor is the standard for DDR4 memory modules, and it is different from the 240-pin form factor used by DDR3 memory. This form factor allows for more pins on the module, which results in increased data transfer rates and improved memory performance.
The 288-pin form factor also allows for a higher density of memory on the module. DDR4 memory modules can have more memory chips per module than DDR3 memory modules, which means that more memory can be packed into a smaller space. This can be beneficial for systems that have limited space for memory expansion.
The P12403-B21 HPE 64GB 2933Mhz RAM uses the 288-pin form factor, which means it is compatible with motherboards that support DDR4 memory and have 288-pin memory slots. It is important to check compatibility before buying, as DDR4 memory will not work with DDR3 motherboards and vice versa.
General Information of this HPE P12403-B21
- Brand Name: HPE
- Model Number or SKU# P12403-B21
- Type: Memory (RAM)
- RAM Type: Pc4-23400
- Product Name: 64GB DDR4 4RX4 Rdimm 2933mhz
Technical Information about 64GB DDR4 Ram
- Storage Capacity: 64GB
- Memory Technology: DDR4 SDRAM
- Number Of Modules: 1 X 64GB
- Bus Speed: 2933mhz DDR4-23400/PC4-2933v
- Data Integrity Check: Ecc
- Signal Processing: Registered
- Cas Latency Timings: Cl21
- Rank Features: 4rx4
- Form Factor: 288-Pin Lrdimm
Physical Characteristics of HPE P12403-B21
- Dimensions (W X D X H) : 8.89 X 19.81 X 1.91 Cm (3.5 X 7.8 X 0.75 In)
- Weight: 0.45 Kg (1 Lb)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
