Description
Product overview for the HPE P19776-B21
In the world of information technology, servers play a crucial role in ensuring the smooth functioning of various applications and services. One such server that stands out is the HPE P19776-B21 ProLiant DL360 Gen10 NC Model. In this detailed exploration, we will dissect its specifications, focusing on key components such as the processor, memory, storage, networking capabilities, and power supply.
Overview of the HPE ProLiant DL360 Gen10 NC Model
The HPE ProLiant DL360 Gen10 NC Model is a 1U rack server designed to deliver high-performance computing in a compact form factor. It comes equipped with cutting-edge technology to meet the demands of modern data centers, offering a balance of power, efficiency, and reliability.
Processing Power: 2nd Gen Intel 8-core Xeon Silver 4208
At the heart of this server lies the powerful 2nd Gen Intel 8-core Xeon Silver 4208 processor. This CPU, with a base clock speed of 2.1 GHz, forms the backbone of the server’s processing capabilities. The 8 cores ensure parallel processing, enabling the server to handle multiple tasks simultaneously, making it suitable for a wide range of applications.
Memory: 16GB DDR4 SDRAM
Memory is a critical aspect of any server, and the HPE ProLiant DL360 Gen10 NC Model doesn’t disappoint. It comes with 16GB of DDR4 SDRAM, providing fast and efficient access to frequently used data. The DDR4 technology ensures higher data transfer rates and improved power efficiency compared to its predecessors, contributing to overall system performance.
Storage: Smart Array 14-port S100i
Storage is a key consideration in server configurations, and the HPE ProLiant DL360 Gen10 NC Model features the Smart Array 14-port S100i. This storage solution offers a balance between performance and reliability, supporting various RAID configurations for data protection and redundancy. The 14 ports provide flexibility for connecting multiple drives, catering to the storage needs of diverse applications.
Networking: 1Gb 4P FLR-T I350-T4V2 Adapter
In the era of interconnected systems, networking capabilities are paramount. The HPE ProLiant DL360 Gen10 NC Model incorporates a 1Gb 4P FLR-T I350-T4V2 Adapter, ensuring fast and reliable network connectivity. With four ports, it allows for efficient data transfer and supports various network configurations to meet the demands of different environments.
Form Factor and Design: 4LFF, 1U Rack Server
The physical design of a server is crucial for efficient space utilization in data centers. The HPE ProLiant DL360 Gen10 NC Model adopts a 1U rack server form factor with 4LFF (Large Form Factor) support. This compact design allows for easy integration into standard server racks, optimizing space while providing scalability for future expansion.
Power Supply: 500W RPS
Power efficiency is a critical aspect of server infrastructure. The HPE ProLiant DL360 Gen10 NC Model is equipped with a 500W Redundant Power Supply (RPS), ensuring continuous operation even in the event of a power supply failure. Redundancy is crucial for minimizing downtime and ensuring the server’s availability in mission-critical applications.
Performance and Use Cases
The combination of a powerful processor, ample memory, versatile storage options, and robust networking capabilities positions the HPE ProLiant DL360 Gen10 NC Model as a high-performance server. It is well-suited for a variety of use cases, including virtualization, database management, cloud computing, and enterprise applications that demand reliability and scalability.
Management and Security Features
HPE servers are renowned for their management and security features. The ProLiant DL360 Gen10 NC Model likely includes HPE’s Integrated Lights Out (iLO) technology, providing remote management capabilities. Additionally, it may incorporate security features such as silicon root of trust and secure firmware updates to safeguard against potential threats.
General Information about the HPE P19776-B21
- Manufacturer: HPE
- Model Number or SKU# P19776-B21
- Product Type: Server
- Server Type: P19776-B21 DL360
Processor and chipset for the Xeon 2.1GHz Server
- CPU: 2nd Gen Intel Silver 4208 / 2.1 GHz
- Max Turbo Speed: 3.2 GHz
- Number Of Cores: 8-core
- CPU Qty: 1
- Max CPU Qty: 2
- CPU Upgradability: Upgradable
- Processor Main Features: Hyper-threading Technology, Intel Turbo Boost Technology 2
- CPU Socket: FCLGA3647 Socket
- Chipset Type: Intel C621
Cache Memory
- Installed Size: L3 Cache – 11 MB
- Cache Per Processor: 11 MB
Memory
- Installed Size: 16 GB / 1.5 TB (max)
- Technology: DDR4 SDRAM
- Effective Memory Speed: 2400 MHz
- Rated Memory Speed: 2933 MHz
- Form Factor: DIMM 288-pin
- Slots: 24 (total) / 23 (empty)
- Features: Registered
- Configuration Features: 1 x 16 GB
- RAM Supported: PC4-20800 – 3.072 TB Load-reduced PC4-20800 – 1.5 TB Registered PC4-20800 – 192 GB Non-volatile PC4-20800 – 6 TB – HPE Persistent Memory
Storage
- Hard Drive: None
- Optical Drive: None
Storage Controllers
- Type: 1 x SATA
- Controller Interface Type: SATA 6Gb/s
- Storage Controller Name: HPE Smart Array S100i SR Software
- Channel Qty: 14
Display & Graphics Controllers
- Video Memory: 16 MB
- Video Interfaces: VGA
Network & Communication
- Interface (Bus) Type: PCI Express 2.1 x4
- Ethernet Ports: 4 x Gigabit Ethernet
- Ethernet Controller: HPE 366FLR
- Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
- Remote Management Protocol: SNMP 3, IPMI 2.0, SMASH CLP
- Remote Management Controller: Integrated Lights-out 5
- Features: Wake On LAN (WOL), PXE Support
- Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1AS, IEEE 802.3az
Expansion / Connectivity: Bays
- 1 (total) / 1 (free) x External Universal Media Bay
- 4 (total) / 4 (free) x Hot-swap 3.5 LFF
Slots
- 1 (total) / 1 (free) x PCIe 3.0 x16 – Three-quarter-length, Full-height
- 1 (total) / 1 (free) x PCIe 3.0 x8 – Low-profile
- 1 (total) / 1 (free) x FlexibleLOM – Three-quarter-length, Full-height (low-profile)
- 1 (total) / 1 (free) x MicroSD Card (internal)
- 1 (total) / 1 (free) x PCIe x16 – Full-height
Interfaces
- 1 x HPE iLO – Type A (1 in front)
- 1 x HPE iLO – RJ-45 (1 rear)
- 5 x USB 3.0 (1 front, 2 rear, 2 internal)
- 1 x VGA (1 rear)
- 4 x LAN (Gigabit Ethernet) – RJ-45 (4 rear)
Miscellaneous
- Included Accessories: 5 x Standard Hot Plug Fans
- Compliant Standards: AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, FIPS 201 PIV, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power Description
- Device Type: Power Supply – Hot-plug
- Power Redundancy: Optional
- Power Redundancy Scheme: 1+1 (with optional power supply)
- Installed Qty: 1
- Max Supported Qty: 2
- Nominal Voltage: AC 120/230 V (50/60 Hz)
- Power Provided: 500 Watt
- 80 Plus Certification: 80 Plus Platinum
Finally, the HPE P19776-B21 ProLiant DL360 Gen10 NC Model is a versatile and powerful server designed to meet the demanding requirements of modern data centers. With its advanced processor, ample memory, flexible storage options, and reliable networking capabilities, it stands as a robust solution for a wide range of applications. Whether deployed for virtualization, database management, or cloud computing, this server offers a compelling combination of performance, efficiency, and scalability.
