Description
The Benefits of the Smart Carrier Technology
The Smart Carrier (SC) technology in the HPE P21135-X21 3.2TB SAS 12GBPS Mixed Use SFF SSD provides several benefits for users. This technology helps improve the performance and reliability of the SSD, and enables better data transfer speeds. The Smart Carrier technology also provides enhanced power management, which helps ensure that the drive operates efficiently and consumes less energy. Additionally, the SC technology can help extend the life of the SSD by helping to prevent damage from shock or vibration, and by providing better heat dissipation. All of these benefits work together to make the HPE P21135-X21 a high-performing, reliable, and energy-efficient storage solution for various applications.
Energy-Efficient Power Management
The HPE P21135-X21 3.2TB SAS 12GBPS Mixed Use SFF Smart Carrier (SC) SSD features energy-efficient power management, which helps ensure that the drive consumes minimal power while still delivering high performance. This is achieved through a combination of hardware and software technologies that help reduce the power consumption of the drive, while still ensuring that it performs at optimal levels. The SC technology also helps improve the power management of the SSD, by enabling better control over the power states of the drive, and by helping to reduce the power consumption during idle periods. The energy-efficient power management in the HPE P21135-X21 SSD helps reduce the overall energy costs of the system, and helps extend the life of the drive by reducing the amount of heat generated. This results in a high-performance, reliable, and cost-effective storage solution for various applications.
High-Performance SAS 12Gbps Interface
The HPE P21135-X21 3.2TB SAS 12GBPS Mixed Use SFF Smart Carrier (SC) SSD features a high-performance SAS 12Gbps interface, which provides fast and reliable data transfer speeds. The SAS interface is a popular and widely-used interface for high-performance storage devices, and provides improved performance compared to other interfaces such as SATA. The 12Gbps SAS interface in the HPE P21135-X21 SSD supports data transfer speeds of up to 12 gigabits per second, which enables fast and efficient transfer of large amounts of data. This makes the drive an ideal choice for high-performance computing applications, where fast and reliable data access is critical. The 12Gbps SAS interface also supports high-speed data transfers between the SSD and the host system, helping to ensure that the system runs at optimal levels. Overall, the high-performance SAS 12Gbps interface in the HPE P21135-X21 SSD provides a fast and reliable storage solution for various applications.
General Information
- Manufacturer: Hewlett Packard Enterprise (HPE)
- MPN: P21135-X21
- Spare Part Number: P22583-001
- SKU: P21135-X21
Technical Features
- Type: Hot-Swap Solid State Drive
- Capacity: 3.2 TB
- Form Factor: 2.5 Inch SFF
- SSD Type: SAS 12GBPS
- Plug Type: Hot Pluggable
- Carrier Type: Smart Carrier (SC)
- Workload Type: Mixed-Use
- Bundled With: HPE Smart Carrier (SC)
- Height: 15 mm (0.60 Inch)
- Weight: 23.98 oz
Drive Performance
- Lifetime Writes: 17121
- Endurance DWPD (Drive Writes Per Day): 3
- Drive Transfer Rate: 12 Gb/sec (external)
- Random Read IOPS (4KiB, Q=16): 135000
- Random Write IOPS (4KiB, Q=16): 120000
- MAX Seq Reads Throughput (MiB/s): 1095
- Max Seq Writes Throughput (MiB/s): 1040
- Random Read Avg. Latency uSec (4KiB, Q1): 98
- Random Write Avg. Latency uSec (4KiB, Q1): 32
- Max Random Read IOPS (4KiB): 210000@Q256
- Max Random Write IOPS (4KiB): 124000@Q64
Power
- Power Consumption: 10.16 Watts
Environmental Parameters
- Min Operating Temperature: 32 °F
- Max Operating Temperature: 140 °F
Dimensions & Weight
- Height: 0.63Inch
- Width: 3.10Inch
- Depth: 5.45Inch
- Weight: 1.50 lbs
Compatibility
- HPE ProLiant DL Series: DL160 Gen10 (2.5 Inch), DL160 Gen10 Base (2.5 Inch), DL160 Gen10 Entry (2.5 Inch), DL180 Gen10 (2.5 Inch), DL180 Gen10 Base (2.5 Inch), DL180 Gen10 SMB (2.5 Inch), DL20 Gen10 (2.5 Inch), DL20 Gen10 Entry (2.5 Inch), DL20 Gen10 Performance (2.5 Inch), DL20 Gen10 solution (2.5 Inch), DL325 Gen10 (2.5 Inch), DL325 Gen10 Base (2.5 Inch), DL325 Gen10 Entry (2.5 Inch), DL325 Gen10 Performance (2.5 Inch), DL325 Gen10 Plus (2.5 Inch), DL325 Gen10 SMB Solution (2.5 Inch), DL325 Gen10 Solution (2.5 Inch), DL360 Gen10 (2.5 Inch), DL360 Gen10 Base (2.5 Inch), DL360 Gen10 Entry (2.5 Inch), DL360 Gen10 High Performance (2.5 Inch), DL360 Gen10 Low (2.5 Inch), DL360 Gen10 Network Choice (2.5 Inch),
- DL360 Gen10 Performance (2.5 Inch), DL360 Gen10 Premium (2.5 Inch), DL360 Gen10 SMB (2.5 Inch), DL360 Gen10 SMB Network Choice (2.5 Inch), DL360 Gen10 Solution (2.5 Inch), DL360 Gen10 Special Server (2.5 Inch), DL385 Gen10 (2.5 Inch), DL385 Gen10 Base (2.5 Inch), DL385 Gen10 Entry (2.5 Inch), DL385 Gen10 High-Performance (2.5 Inch), DL385 Gen10 Performance (2.5 Inch), DL385 Gen10 Plus (2.5 Inch), DL385 Gen10 Plus Entry (2.5 Inch), DL385 Gen10 SMB (2.5 Inch), DL385 Gen10 Solution (2.5 Inch), DL560 Gen10 (2.5 Inch), DL560 Gen10 Base (2.5 Inch), DL560 Gen10 Entry (2.5 Inch), DL560 Gen10 Performance (2.5 Inch), DL580 Gen10 (2.5 Inch), DL580 Gen10 Base (2.5 Inch), DL580 Gen10 Entry (2.5 Inch), DL580 Gen10 Performance (2.5 Inch)
- HPE ProLiant ML Series: ML350 Gen10 (2.5 Inch), ML350 Gen10 Base (2.5 Inch), ML350 Gen10 Entry (2.5 Inch), ML350 Gen10 High Performance (2.5 Inch), ML350 Gen10 Performance (2.5 Inch), ML350 Gen10 SMB (2.5 Inch), ML350 Gen10 Solution (2.5 Inch), ML350 Gen10 Special Server (2.5 Inch), ML350 Gen10 Sub-Entry (2.5 Inch)
