Description
Product Overview
The P24470-B21 HPE Intel Xeon 24 Core Gold 6240R 2.4GHz 35.75MB Smart Cache 10.4GT/S UPI Speed Socket Fclga3647 14NM 165W Processor Kit For DL380 Gen10 Server is a high-performance processor designed for use in HPE DL380 Gen10 servers. This processor kit is built on the latest 14nm architecture and features 24 cores with a base clock speed of 2.4GHz. In this article, we will take a closer look at the technical specifications of this processor kit and its capabilities.
Processor Architecture
The P24470-B21 HPE Intel Xeon 24 Core Gold 6240R processor is built on the latest 14nm architecture, which makes it highly efficient and powerful. The processor has a base clock speed of 2.4GHz, which can be boosted up to 4.0GHz with Intel Turbo Boost Technology. This makes it suitable for running even the most demanding applications with ease.
Cores and Threads
The processor has 24 cores, which means it can handle up to 24 threads simultaneously. This is particularly useful for applications that require a high level of parallel processing, such as scientific simulations, big data analysis, and machine learning.
Smart Cache Memory
The processor comes with 35.75MB of Smart Cache memory, which helps in improving its performance. The Smart Cache memory is divided into three levels – L1, L2, and L3. L1 and L2 cache memory are dedicated to individual cores, while L3 cache memory is shared among all the cores. The Smart Cache memory helps in reducing the latency of memory access, which results in faster performance.
Socket and Power Consumption
The processor is designed to fit into a Socket Fclga3647, which is a high-end server socket. The processor has a maximum power consumption of 165W, which is relatively high but necessary to deliver the required performance. The processor also supports up to six channels of DDR4 memory with a maximum memory speed of 2933 MHz.
Compatible Servers
The P24470-B21 HPE Intel Xeon 24 Core Gold 6240R processor is designed specifically for the HPE DL380 Gen10 server. This server is a highly scalable and versatile server that is suitable for a wide range of applications. The DL380 Gen10 server is designed to support up to two processors, which means you can install two P24470-B21 processors for even greater performance.
Summary, The P24470-B21 HPE Intel Xeon 24 Core Gold 6240R 2.4GHz 35.75MB Smart Cache 10.4GT/S UPI Speed Socket Fclga3647 14NM 165W Processor Kit For DL380 Gen10 Server is a powerful and efficient processor that is designed to handle even the most demanding applications with ease. With 24 cores and 35.75MB of Smart Cache memory, this processor is capable of running multiple threads and reducing the latency of memory access. The processor is compatible with the HPE DL380 Gen10 server and is designed to fit into a Socket Fclga3647. If you’re looking for a high-performance processor for your server, the P24470-B21 is definitely worth considering.
Specifications
- Brand : Hewlett Packard Enterprise(HPE)
- Part Number : P24470-B21
- Type : Processor
- Sub-Type : Intel Xeon 24 Core
Technical Information
- Processor Core : 24-Core
- Clock Speed : 2.40GHz
- Max Turbo Frequency : 4.00GHz
- Ultrapath Interconnect UPI Speed : 10.4GT/S
- No. Of UPI Links : 2
- Instruction Set : 64-Bit
- Instruction Set Extensions : Intel® Sse4.2, Intel® Avx, Intel® Avx2, Intel® Avx-512
Cache Memory Detail
- Smart Cache : 35.75MB
- Lithography : 14NM
- Max Thermal Design Power TDP : 165W
- Compatible Processor Socket : Fclga3647
Memory Specifications
- Max Memory Size Dependent On Memory Type : 1TB
- Memory Types : DDR4-2933
- Maximum Memory Speed : 2.9GHz
- Max No. Of Memory Channels : 6
- Ecc Memory Supported : Yes
