Description
Capacity and Frequency
Capacity refers to the amount of memory that a RAM module can store. The HMA84GR7CJR4N-WM is a 32GB DDR4 RAM module, meaning it can store up to 32GB of data. This makes it a suitable option for high-performance computing tasks that require large amounts of memory.
Frequency, on the other hand, refers to the speed at which the RAM module operates. The HMA84GR7CJR4N-WM operates at a frequency of 2933MHz, which is the speed at which data can be transferred between the RAM and the CPU. Higher frequency often results in improved system performance, making the 2933MHz frequency of the HMA84GR7CJR4N-WM an attractive feature for demanding applications.
Smart Memory Functionality and Benefits
The HMA84GR7CJR4N-WM does not have built-in smart memory functionality. Smart memory refers to RAM modules that are equipped with additional features or functions beyond basic memory storage and retrieval.
However, the HMA84GR7CJR4N-WM still offers several benefits over traditional DDR3 RAM, as it is based on the DDR4 technology. Some of these benefits include improved memory performance, higher memory density, reduced power consumption, and improved reliability. The use of DDR4 technology also means that the HMA84GR7CJR4N-WM is able to deliver faster data transfer speeds and improved system responsiveness.
Additionally, the HMA84GR7CJR4N-WM features ECC (Error Correction Code) functionality, which helps to detect and correct errors in the data being stored and processed by the RAM. This helps to ensure the reliability and stability of the system, making the HMA84GR7CJR4N-WM a suitable choice for applications that require high levels of data accuracy.
Pin Configuration and Form Factor
The pin configuration of a RAM module refers to the number and arrangement of pins on the module’s edge connector. The HMA84GR7CJR4N-WM is a 288-pin DDR4 RAM module, meaning it has 288 pins arranged in a specific pattern that allows it to connect to the appropriate socket on the motherboard.
The form factor of a RAM module refers to its physical size and shape. The HMA84GR7CJR4N-WM has a standard DDR4 form factor, meaning it conforms to the specifications for DDR4 modules as defined by JEDEC (Joint Electron Device Engineering Council). This form factor is commonly used for DDR4 modules and is compatible with most DDR4-compatible motherboards.
Having the correct pin configuration and form factor is important for ensuring that a RAM module can be installed and used in a system. The 288-pin configuration and standard DDR4 form factor of the HMA84GR7CJR4N-WM make it a suitable choice for use in most DDR4-compatible systems.
Installation and Setup Instructions
Installing the HMA84GR7CJR4N-WM into a system is a straightforward process that typically involves the following steps:
- Ensure that the system is powered off and unplugged.
- Open the system’s case to access the motherboard.
- Locate the DDR4 memory slots on the motherboard.
- Release the retention clips on either side of the DDR4 slot to open the slot.
- Align the notches on the HMA84GR7CJR4N-WM module with the notches on the DDR4 slot.
- Gently insert the HMA84GR7CJR4N-WM module into the DDR4 slot until the retention clips click into place.
- Close the system’s case.
- Power on the system and enter the BIOS/UEFI setup utility.
- Configure the system to use the new RAM. This may involve adjusting memory settings, enabling XMP profiles, or adjusting the system’s memory configuration.
- Save the changes and exit the BIOS/UEFI setup utility.
- Boot into the operating system to ensure that the RAM is recognized and functioning correctly.
It is important to follow the installation and setup instructions carefully to ensure that the HMA84GR7CJR4N-WM is installed and configured correctly. Additionally, some motherboards may have specific requirements for installing and configuring DDR4 memory, so it is important to consult the motherboard manual or manufacturer’s website for specific instructions.
General Information of this Hynix HMA84GR7CJR4N-WM
- Brand Name: Hynix
- Model Number or SKU# HMA84GR7CJR4N-WM
- Type: Memory (RAM)
- RAM Type: PC4-23400
- Product Name: 32GB DDR4 SDRAM Memory Module
Technical Information about 32GB DDR4 Ram
- Storage Capacity: 32GB
- Memory Technology: DDR4 SDRAM
- Number Of Modules: 1 X 32GB
- Bus Speed: 2933mhz DDR4-23400/PC4-2933V
- Data Integrity Check: ECC
- Signal Processing: Registered
- Cas Latency Timings: Cl21
- Rank Features: 2rx4
- Form Factor: 288-pin Rdimm
Physical Characteristics of Hynix Memory
- Dimensions (W X D X H) : 8.89 X 19.81 X 1.91 Cm (3.5 X 7.8 X 0.75 In)
- Weight: 0.45 Kg (1 Lb)
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
