Introduction to BX806736152 Intel Xeon Processor
The BX806736152 Intel Xeon Processor is a high-performance server processor designed for use in data centers and other demanding computing environments. It features 22 cores,
Processor Cores and Clock Speed
L3 Cache Size and Performance
The BX806736152 Intel Xeon Processor features a large 30.25MB L3 cache, which acts as a high-speed buffer between the processor and main memory. This helps to increase the processor’s overall performance by reducing the time it takes to access frequently used data. The L3 cache also helps to improve the processor’s ability to handle large, complex data sets, making it well-suited for demanding workloads in data centers and other high-performance computing environments.
System Requirements and Recommendations
The BX806736152 Intel Xeon Processor is designed to be used in server systems and other high-performance computing environments. To use this processor, the system must have a compatible socket type (FCLGA3647) and support for the 10.4 GT/s UPI speed. Other system requirements and recommendations may include:
- A compatible chipset
- Adequate cooling and power supply
- Enough RAM and storage capacity to support the workload
- A compatible operating system, such as Windows Server or a Linux distribution
- BIOS updates or firmware upgrades to ensure compatibility and optimal performance
It’s recommended to consult the processor datasheet or vendor documentation for the most up-to-date information on system requirements and recommendations.
General Information
- product type : server processor
- product manufacturer : intel corporation
- manufacturer part number : BX806736152
- product model : GOLD 6152
Technical Information
- processor core : 22-core
- clock speed : 2.10GHz
- max turbo frequency : 3.70GHz
- ultra path interconnect(UPI) speed : 10.4GT/S
- no. Of UPI links : 3
- instruction set : 64-bit
- instruction set extensions : INTEL® SSE4.2, INTEL® AVX, INTEL® AVX2, INTEL® AVX-512
Cache Memory Detail:
- L3 CACHE : 30.25MB
- LITHOGRAPHY : 14NM
MAX Thermal Design Power TDP:
- 140W
Compatible Processor Socket :
- FCLGA3647
Memory Specifications:
- max memory size (dependent on memory type) : 768GB
- memory types : DDR4-2666
- maximum memory speed : 2.67GHz
- max no. Of memory channels : 6
- ECC memory supported : yes
