Description
Product overview Intel CM8064402018700
The Intel Xeon E5-4660V3 Processor is a powerful 14-core processor that has been designed specifically for use in high-performance computing environments. It is based on the Haswell microarchitecture, which was introduced by Intel in 2013, and has been optimized for server and workstation applications..
Processor Architecture and Design
The Intel Xeon E5-4660V3 Processor is a 64-bit processor that supports both single- and dual-socket configurations. It has a base clock speed of 2.1 GHz, which can be boosted to 3.2 GHz using Intel’s Turbo Boost technology. The processor has a thermal design power (TDP) of 120 watts, which means it is designed to consume a maximum of 120 watts of power under normal operating conditions.
The processor is built using Intel’s 22-nanometer manufacturing process, which allows for the creation of transistors that are smaller and more power-efficient than those used in previous generations of processors. The processor also includes Intel’s Hyper-Threading technology, which allows each core to execute two threads simultaneously, effectively doubling the number of cores.
Socket Type and Compatibility
The Intel Xeon E5-4660V3 Processor uses the Socket FCLGA-2011, which is a high-performance socket designed for use with server and workstation motherboards. This socket is compatible with the Intel X99 chipset, which is used in many high-end server and workstation motherboards.
Cache Size and QPI Speed
The processor includes a large 35MB L3 cache, which is designed to improve performance by reducing the amount of time the processor needs to access data from system memory. The cache is shared between all 14 cores, which means that each core has access to a portion of the cache.
The processor also includes a QuickPath Interconnect (QPI) interface, which is used to connect the processor to other system components, such as memory and input/output devices. The QPI speed of the Intel Xeon E5-4660V3 Processor is 9.6 GT/s, which means that it can transfer data at a rate of 9.6 billion transfers per second.
Performance and Benchmarking
The Intel Xeon E5-4660V3 Processor is designed for use in high-performance computing environments, where it can deliver excellent performance in a variety of applications, including data analytics, scientific computing, and 3D rendering. The processor’s large number of cores and high clock speed make it particularly well-suited for applications that require significant amounts of parallel processing power.
When benchmarked using the SPEC CPU2006 benchmark, the Intel Xeon E5-4660V3 Processor achieved a score of 454 for the integer rate base and 498 for the floating-point rate base. These scores indicate that the processor is capable of delivering excellent performance in both integer and floating-point operations.
In summary, the CM8064402018700 Intel Xeon E5-4660V3 Processor is a powerful 14-core processor that has been designed specifically for use in high-performance computing environments. It is built using Intel’s 22-nanometer manufacturing process and includes a large 35MB L3 cache and a QuickPath Interconnect (QPI) interface with a speed of 9.6 GT/s.
General Information about the Intel CM8064402018700
- Manufacturer: Intel
- Model Number or SKU# CM8064402018700
- Product Type : Server Processor
Technical information
- Processor core : 14-core
- Clock speed : 2.1GHz
- Max turbo frequency : 2.9GHz
- Quick path interconnect(QPI) speed : 9.6GT/s
- Instruction set : 64-bit
- Instruction set extensions : AVX 2.0
Cache Memory Detail
- L3 Cache : 35MB
- Lithography : 22NM
- Max Thermal Design Power (TDP) : 120W
- Compatible Processor Socket : FCLGA-2011
Memory specifications
- Max Memory Size (Dependent On Memory Type) : 768 GB
- Memory types : ddr4
- Max # of memory channels : 4
- Max memory bandwidth : 68gb/s
- Physical address extensions : 46-bit
- Ecc memory supported : YES
Expansion options
- Pci express revision : 3.0
- Pci express configurations : X4, X8, X16
- Max # of pci express lanes : 40
