Description
Product Overview
The E10G41AT2 Intel 10 Gigabit AT2 Server Adapter is a high-performance network card designed for use in servers and workstations. It provides a single RJ-45 port, which is capable of providing a maximum transfer rate of 10 Gbps. The card is designed to fit into a PCI Express slot and is compatible with a range of operating systems. In this article, we will explore the features of this network card in detail.
Features
The E10G41AT2 Intel 10 Gigabit AT2 Server Adapter provides a single RJ-45 port, which is capable of providing a maximum transfer rate of 10 Gbps. This means that the card can provide a high-speed connection for applications that require large amounts of data transfer. The card is designed to be used with twisted-pair cabling, which provides high-speed connectivity over short to medium distances.
The card is also designed to be a low-profile card, which means that it is designed to fit into servers and workstations with limited space. This makes it an ideal choice for organizations that require high-speed connectivity in compact systems.
Compatibility
The E10G41AT2 Intel 10 Gigabit AT2 Server Adapter is designed to be compatible with a wide range of operating systems, including Microsoft Windows, Linux, and VMware ESXi. The card is also designed to work with a range of network protocols, including Ethernet and TCP/IP.
Advanced Features
In addition to its high-speed connectivity and broad compatibility, the E10G41AT2 Intel 10 Gigabit AT2 Server Adapter also includes a range of advanced features designed to enhance performance and reliability. These features include:
Virtualization support: The card includes support for virtualization technologies such as VMware vSphere and Microsoft Hyper-V, which allows for the creation of virtual networks and virtual machines.
Quality of Service (QoS): The card includes advanced QoS features that allow for the prioritization of network traffic based on application and user requirements. This helps to ensure that critical applications receive the necessary bandwidth and performance.
Network management features: The card includes support for Intel Ethernet Flow Director, which allows for the efficient distribution of network traffic across multiple processors. The card also includes support for Intel Ethernet Power Management, which helps to reduce power consumption and extend the life of the card.
Security features: The card includes advanced security features such as IEEE 802.1x authentication and Secure Sockets Layer (SSL) support.
Teaming support: The card includes support for teaming, which allows for the creation of multiple connections between the card and the network switch. This helps to provide redundancy and failover capabilities, which can help to ensure network availability.
In summary, the E10G41AT2 Intel 10 Gigabit AT2 Server Adapter is a high-performance network card designed for use in servers and workstations. The card provides a single RJ-45 port, which is capable of providing a maximum transfer rate of 10 Gbps, and is designed to fit into a PCI Express slot. The card is also designed to be a low-profile card, which makes it an ideal choice for organizations that require high-speed connectivity in compact systems. The card includes a range of advanced features designed to enhance performance and reliability, making it an excellent choice for organizations that require high-speed connectivity and advanced network capabilities.Main Information about the Dell E10G41AT2
- Manufacturer: Dell
- Part Number or SKU# E10G41AT2
- Device Type: Network Adapter
Technical Information
- Form Factor : Plug-In Card Low Profile
- Interface (Bus) Type : PCI Express 2.0 X8
Networking
- Connectivity Technology : Wired
- Cabling Type : Ethernet 1000Base-T, Ethernet 10Gbase-T
- Data Link Protocol : Ethernet, 10 GIGABIT Ethernet
- Data Transfer Rate : 10 GBPS
- Network / Transport Protocol : TCP/IP, UDP/IP, ISCSI
- Remote Management Protocol : SNMP, DMI 2.0
- Status Indicators : Link Activity
Features
- Flow Control, Fault Tolerance, Load Balancing, Remote Reboot, VLAN Support, Packet Filtering, IPV6 Support, Intel I/O Acceleration Technology (I/OAT), Virtual Machine Device Queues (VMDQ)
- Compliant Standards : IEEE 802.3, IEEE 802.1Q, IEEE 802.1P, IEEE 802.3AD (LACP)
Processor / Memory
- Processor : 1 X 82598EB Intel
Expansion / Connectivity
- Interfaces : 1 X Network Ethernet 10GBASE-T RJ-45
- Compatible Slots : 1 X PCI Express 2.0 X8 Low-Profile.
