Description
Advanced Technologies of Server Adapter
The E10G42AFDA Intel PCI Express 2.0 X8 10GBPS 10GIGABIT AT2 Dual Port Server Adapter is designed to provide advanced technologies for a wide range of networking applications.
One of the advanced technologies that the adapter supports is Intel Virtualization Technology (VT-c). This technology helps to improve the performance and security of virtualized environments by offloading tasks from the host CPU to the network adapter. This can help to reduce CPU utilization and improve network performance, allowing the host CPU to focus on other tasks.
The adapter also supports TCP/UDP segmentation offload (TSO/USO), which allows the adapter to offload the segmentation of TCP and UDP packets to the network adapter, rather than having the host CPU perform this task. This can help to reduce CPU utilization and improve network performance by allowing the host CPU to focus on other tasks.
The adapter also supports Large Receive Offload (LRO) which is a feature that allows the adapter to combine multiple incoming packets into a single larger packet before passing them to the host CPU. This can help to reduce CPU utilization and improve network performance by reducing the number of packets that need to be processed by the host CPU.
Additionally, the adapter supports Data Center Bridging (DCB) which is a set of standards that are designed to improve the performance and reliability of data center networks. DCB includes technologies such as Priority Flow Control (PFC) and Enhanced Transmission Selection (ETS) which can be used to prioritize network traffic and ensure that critical applications receive the bandwidth they need.
Quality Components
E10G42AFDA is a network adapter made by Intel. It is a PCI Express 2.0 adapter, which means it connects to a computer’s motherboard using the PCI Express interface. It has a data transfer rate of 10 Gbps, which is very fast, and it is able to handle 10 Gigabit Ethernet. The “AT2” in the name refers to the adapter’s ability to support both copper and optical cables, while the “Dual Port” means that it has two ports, allowing for connection to two separate network devices. The “Server Adapter” indicates that it is designed for use in servers rather than consumer PCs, and the “Quality Components” likely refers to the use of high-quality materials and construction in the adapter’s manufacture.
Resiliency and High Availability
The “Resiliency and High Availability” feature of the E10G42AFDA Intel PCI Express 2.0 X8 10GBPS 10Gigabit AT2 Dual Port Server Adapter refers to its ability to provide a reliable and robust network connection for servers. This feature can help to ensure that the server remains connected to the network even in the event of an interruption or failure.
One example of this is that the adapter can support NIC teaming, which allows multiple network interfaces to be grouped together to create a single logical interface. This can provide redundancy, so that if one of the interfaces fails, the other interfaces will continue to provide network connectivity.
Another example is that it can support advanced features such as Link Aggregation Control Protocol (LACP) and teaming options such as Switch Independent, Adaptive Load balancing, and IEEE 802.3ad Link Aggregation Control Protocol (LACP) which can provide load balancing and failover protection.
Overall, the part adapter is designed to provide a high level of reliability and availability for servers, helping to ensure that the servers can remain connected to the network even in the event of an interruption or failure.
Product Details:
Manufacturer: Intel
MPN: E10G42AFDA
Type: Networking
Networking Type: NIC
Product Name: 10 Gigabit
SKU: E10G42AFDA
Dimensions: 8.9 x 5.8 x 1.1 inches
Networking:
Device Type : Network Adapter 2 Ports
Form Factor : Plug-In Card Low Profile
Interface (Bus) Type : PCI Express 2.0 X8
Connectivity Technology : Wired
Data Link Protocol : 10 Gigabit Ethernet
Data Transfer Rate : 10 GBPS
Network / Transport Protocol : TCP/IP, UDP/IP, ISCSI
Remote Management Protocol : SNMP, DMI 2.0
Status Indicators : Link Activity
Features : Flow Control, Fault Tolerance, Load Balancing, VLAN Support, Packet Filtering, IPV6 Support, Intel I/O Acceleration Technology (I/Oat)
Compliant Standards : Ieee 802.3, Ieee 802.1q, Ieee 802.1p, Ieee 802.11a, Ieee 802.11e
Processor / Memory:
Processor : 1 X 82598EB Intel
Expansion / Connectivity
Expansion Slots Total (Free) : 2 ( 2 ) X SFP+
Compatible Slots : 1 X PCI Express X8 Low-Profile.
