Description
Processor Clock Speed and Cache Size
The Processor Clock Speed and Cache Size are important factors that affect the performance of a processor. Here’s some more information about these two features for the SRF8W Intel Xeon Gold 6230 Processor:
Processor Clock Speed: The SRF8W Intel Xeon Gold 6230 Processor has a base clock speed of 2.10 GHz, which means that it can execute 2.1 billion clock cycles per second. However, the processor also has a turbo boost feature, which can increase the clock speed up to 3.9 GHz for short periods of time, depending on the workload and thermal conditions. Higher clock speeds generally translate to faster processing times, but they can also result in higher power consumption and heat generation.
Cache Size: The SRF8W Intel Xeon Gold 6230 Processor has a large 28MB SmartCache, which is shared across all 20 cores. The cache is a high-speed memory buffer that stores frequently used data and instructions, so that the processor can access them quickly without having to retrieve them from main memory. The larger the cache size, the more data can be stored close to the processor, which can lead to faster execution times and lower latency. However, larger caches can also increase the cost and power consumption of the processor.
Advanced Instruction Set Architecture (ISA) Features
The SRF8W Intel Xeon Gold 6230 Processor supports several Advanced Instruction Set Architecture (ISA) Features that can help improve performance, security, and efficiency. Here are some examples:
- AVX-512: This instruction set extension allows the processor to perform vector operations on 512-bit registers, which can lead to significant speedups in certain workloads such as scientific simulations, image and video processing, and machine learning.
- AES-NI: This instruction set extension provides hardware acceleration for AES encryption and decryption operations, which can improve performance and security in applications that require data encryption.
- SHA Extensions: These instruction set extensions provide hardware acceleration for Secure Hash Algorithms (SHA-1, SHA-256, and SHA-512), which are commonly used in cryptographic applications.
- Intel Turbo Boost Technology: This feature allows the processor to dynamically increase its clock speed when more performance is needed, up to a certain maximum frequency. This can help improve single-threaded performance in workloads that can benefit from higher clock speeds.
- Intel Hyper-Threading Technology: This feature allows each physical core in the processor to execute multiple threads simultaneously, which can improve performance in workloads that can take advantage of parallelism.
- Intel Virtualization Technology (VT-x): This feature provides hardware support for virtualization, which can help improve performance and security in virtualized environments.
- Intel Advanced Vector Extensions 2 (AVX2): This instruction set extension provides hardware acceleration for vector operations on 256-bit registers, which can further improve performance in applications that can take advantage of parallelism.
These are just a few examples of the Advanced ISA features supported by the SRF8W Intel Xeon Gold 6230 Processor. By taking advantage of these features, software developers can create applications that can take advantage of the unique capabilities of the processor to achieve better performance, efficiency, and security.
Application and Workload Performance Benchmarks
Application and Workload Performance Benchmarks are used to evaluate the performance of a processor under different workloads and applications. Here are some examples of benchmarks that have been used to test the performance of the SRF8W Intel Xeon Gold 6230 Processor:
- SPEC CPU 2017: This benchmark suite measures the performance of the processor in various compute-intensive workloads, such as scientific simulations, video encoding, and financial modeling.
- SPECjbb2015: This benchmark measures the performance of the processor in a Java-based application server environment, which is commonly used in enterprise applications.
- Geekbench: This benchmark measures the performance of the processor in various single-core and multi-core workloads, such as image processing, cryptography, and machine learning.
- STREAM: This benchmark measures the memory bandwidth and latency of the processor, which can be important factors in certain memory-intensive workloads.
- LINPACK: This benchmark measures the performance of the processor in solving a system of linear equations, which is commonly used in scientific and engineering applications.
- HPC Challenge: This benchmark measures the performance of the processor in various high-performance computing workloads, such as parallel matrix multiplication and FFTs.
By running these and other benchmarks on the SRF8W Intel Xeon Gold 6230 Processor, users can get an idea of how the processor performs in different workloads and applications, and compare its performance to other processors on the market. However, it’s important to keep in mind that benchmark results are just one aspect of processor performance, and real-world performance can vary depending on factors such as system configuration, software optimization, and workload characteristics.
General Information
- Product Type : Server Processor
- Product Manufacturer : Intel Corporation
- Product Model : Gold 6230
Technical information
- Processor Core : 20-Core
- Clock Speed : 2.10GHz
- Max Turbo Frequency : 3.90GHz
- Ultrapath Interconnect(UPI) Speed : 10.4GT/S
- No. Of UPI Links : 3
- Instruction Set : 64-Bit
- Instruction Set Extensions : Intel® AVX-512
- Smart Cache : 28MB
- Lithography : 14NM
- Max Thermal Design Power (TDP) : 125W
- Compatible Processor Socket : FCLGA3647
Memory specifications
- Max Memory Size (Dependent On Memory Type) : 1TB
- Memory Types : DDR4-2933
- Maximum Memory Speed : 2.9GHz
- Max no. Of memory channels : 6
- ECC Memory Supported : Yes.
