Description
Introduction to the Intel Xeon Silver 4214 Processor
The Intel Xeon Silver 4214 is a server-class processor designed for enterprise-level computing applications. It belongs to the Intel Xeon Scalable family of processors and was first introduced in 2019. The processor is based on the Skylake microarchitecture and is manufactured using the 14nm process technology. It has 12 cores and 24 threads, with a base clock speed of 2.20GHz and a maximum turbo frequency of 3.20GHz. The processor is designed to deliver high performance, reliability, and security for data center applications such as cloud computing, virtualization, and high-performance computing. The Intel Xeon Silver 4214 is equipped with a 17MB Intel Smart Cache, which helps to increase performance by reducing latency and improving data access times. It also supports advanced technologies such as Intel Hyper-Threading, Intel Turbo Boost Technology 2.0, and Intel Virtualization Technology (VT-x), which allow for better utilization of system resources and faster data processing.
Processor Architecture and Design
The Intel Xeon Silver 4214 processor is based on the Skylake microarchitecture, which is the successor to the Broadwell microarchitecture. The Skylake microarchitecture was introduced in 2015 and was designed to provide better performance and efficiency than its predecessors. The processor has a maximum of 12 cores and 24 threads, with a base clock speed of 2.20GHz and a maximum turbo frequency of 3.20GHz.
The processor has a number of features that improve its performance and efficiency. It supports DDR4 memory with a maximum capacity of 1.5TB, which allows for faster data transfer rates and improved overall system performance. The processor also supports Intel Advanced Vector Extensions (AVX) 512, which is an instruction set that enables higher performance for compute, storage, and networking workloads.
The processor is designed with Intel Turbo Boost Technology 2.0, which allows it to dynamically adjust its clock speed based on the workload. This enables the processor to provide maximum performance when needed while also conserving power when the workload is light.
The Intel Xeon Silver 4214 processor also supports Intel Hyper-Threading Technology, which allows each core to process multiple threads simultaneously. This feature improves the processor’s ability to handle multiple tasks at once, resulting in better overall system performance.
Specifications and Features
Here are some of the key specifications and features of the Intel Xeon Silver 4214 processor:
- Architecture: Skylake
- Socket: FCLGA3647
- Number of cores: 12
- Number of threads: 24
- Base clock speed: 2.20GHz
- Max turbo frequency: 3.20GHz
- Cache: 17MB Intel Smart Cache
- Manufacturing process: 14nm
- TDP: 85 watts
- Memory support: DDR4 with a maximum capacity of 1.5TB
- Advanced Technologies:
- Intel Hyper-Threading Technology
- Intel Turbo Boost Technology 2.0
- Intel Virtualization Technology (VT-x)
- Intel Advanced Vector Extensions (AVX) 512
- Intel AES-NI
- Intel Trusted Execution Technology (TXT)
- Intel Run Sure Technology
- Intel Platform Trust Technology (PTT)
- Intel QuickAssist Technology (QAT)
The Intel Xeon Silver 4214 processor is designed to deliver high performance, reliability, and security for data center applications such as cloud computing, virtualization, and high-performance computing. It features a high core count, support for advanced technologies, and a large cache size, which makes it well-suited for compute-intensive workloads. It also supports a range of advanced security features, which helps to protect data and ensure system integrity. Overall, the Intel Xeon Silver 4214 processor is a powerful and flexible solution for demanding data center environments.
General Information
- Product Type : Server Processor
- Product Manufacturer : Intel Corporation
- Product Model : Silver 4214
Technical Information
- Processor Core : 12 Core
- Clock Speed : 2.20GHz
- Max Turbo Frequency : 3.20GHz
- Ultrapath Interconnect(UPI) Speed : 9.6GT/S
- No. Of UPI Links : 2
- Instruction Set : 64-Bit
- Instruction Set Extensions : Intel AVX-512
- Smart Cache : 17MB
- Lithography : 14NM
- Max Thermal Design Power (TDP) : 85W
- Compatible Processor Socket : FCLGA3647
- Max Memory Size (Dependent On Memory Type) : 1TB
- Memory Types : DDR4-2400
- Maximum Memory Speed : 2.40GHz
- Max No. Of Memory Channels : 6
- ECC Memory Supported : Yes.
