Description
Mixed Use SSD
The Samsung MZ-XL512T0 is a 12.8TB internal solid state drive (SSD) that uses the PCI Express (PCIe) interface and the NVMe protocol. The drive is designed for mixed-use workloads, which means it can handle a combination of read-intensive and write-intensive tasks. This drive is part of Samsung’s PM1735 series. This is a high-performance SSD with large capacity, it designed for enterprise use cases like data center, storage solution and other applications that require high storage density and high throughput.
High-performance
The Samsung MZ-XL512T0 is a high-performance solid state drive that is designed to handle a wide range of workloads. It uses the NVMe protocol, which is optimized for flash-based storage and can provide fast data transfer speeds.
In terms of sequential read and write speeds, the drive is specified to have up to 3,500 MB/s and 3,300 MB/s respectively. Random read and write IOPS is specified to have up to 1,100,000 IOPS and 600,000 IOPS respectively.
As with any solid-state drive, performance will depend on several factors, such as the workload being run and the system’s configuration. But, in general the drive provide high throughput and low latency, making it well-suited for enterprise-level tasks like data center and high-performance computing applications.
It also supports features like power-loss protection and secure erase, which ensures the data security and integrity.
Exceptional Reliability
The Samsung MZ-XL512T0 is a high-capacity, enterprise-class solid-state drive (SSD) designed for use in data centers and other demanding storage applications. It has a storage capacity of 12.8 terabytes (TB) and uses the NVMe (Non-Volatile Memory Express) protocol to communicate with the host computer.
The SSD is built with Samsung’s own 3D TLC NAND flash memory which is known for its high performance and reliable data protection. It uses a PCI Express 4.0 x4 interface, which supports a transfer rate of up to 64 gigatransfers per second (GT/s) allowing for faster data transfer speeds compared to other interfaces. This specific model is part of Samsung’s PM1735 SSD lineup, which is a NVMe SSD with high-performance and reliability.
It has several enterprise-grade features that contribute to its reliability, such as Enhanced Secure Erase (ESE) which is a firmware-based data sanitization that allows users to quickly and easily erase data from SSDs in a secure manner, suitable for IT departments and data centers that are required to sanitize data on a regular basis. The drive also equipped with Device Sleep (DevSleep) which reduces the power consumption and noise level during idle periods, making the drive energy efficient and long-lasting. It also has Power loss protection that helps protect data from power interruption and damage, which can help prevent data loss and corruption during unexpected power failures.
Additionally, the drive has a specified endurance of 3 DWPD (Drive Writes Per Day) for 5 years under typical client workloads, this means that the drive can sustain up to 3 times the amount of writes per day for 5 years, which is a pretty good indicator of its reliability over time.
All these features, along with its high performance and high-capacity, make the Samsung an ideal choice for use in mission-critical systems, where data integrity and availability are of the utmost importance.
Detail Information about this Samsung MZ-XL512T0
- Part Number or SKU# MZ-XL512T0
- Manufacturer: Samsung
- Type: Solid State Drive
- Interface Type: PCI-Express
Key Feature of 12.8TB Solid State Drive
- Features : Enterprise
- Capacity: 12.8TB
- Form Factor: 2.5Inch
Expansion & Connectivity :
- Interfaces : 1 X Pci Express 4.0 X8 (nvme)
- Compatible Bay : 2.5
Dimensions & Weight for PCI-Express SSD
- Height: 0.6 inch
- Width: 2.7 inch
- Depth: 3.9 inch
- Weight: 0.35 lbs
Performance
- Drive Writes Per Day (dwpd) : 3
- Internal Data Rate : 8000 Mbps (read) / 3800 Mbps (write)
- 4kb Random Read : 1500000 Iops
- 4kb Random Write : 250000 Iops
Extreme performance
- Featuring support for PCIe Gen 4
- the PM1733 delivers up to 7GB/s Sequential and 1.5M IOPS Random Read speeds
- making it the highest performing SSD ever.
Revolutionary Reliability
- Samsung’s new Fail-in-Place
- technology coupled with V-NAND
- Machine Learning gives the PM1733
- unmatched durability
Unmatched Flexibility
- The PM1733 supports a range of capacities
- from 1.6TB to an industry leading 15.36TB
- In addition each PM1733 can be virtually provisioned
- offering up to 64 separate virtual drives
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
