Description
Workload Performance
The Seagate X16 14TB 7.2K RPM SAS-12GBPS 3.5inch hard drive (model number 2KG213-003) is a high-capacity enterprise-grade hard drive that is designed for use in data centers and other demanding storage environments. It has a large storage capacity of 14TB, which makes it suitable for storing large amounts of data. The drive spins at 7200 RPM, which provides relatively fast data access times compared to other hard drives. It also has a SAS interface that supports data transfer speeds of up to 12 Gbps, which is faster than the standard SATA interface. This hard drive is designed to be reliable and durable, with features such as vibration and shock resistance to help protect the data stored on it.
Compatibility
The 2KG213-003 Seagate X16 14TB 7.2K RPM SAS-12GBPS hard drive is compatible with servers and other devices that have a SAS-12GB/s interface and support for 3.5-inch hard drives. It is also backward compatible with SAS-6GB/s interfaces. It is not compatible with devices that use the SATA interface. Additionally, it is important to check the physical form factor and power requirements of the drive before installing it in a server or other device to ensure compatibility.
It’s also worth noting that the drive’s 14TB capacity will require a system that supports Advanced Format (AF) technology which is a standard used by most of the newer hard drives.
High Reliability
The 2KG213-003 Seagate X16 14TB 7.2K RPM SAS-12GBPS hard drive is designed to be a reliable and durable storage solution for data centers and other demanding environments. Seagate, the manufacturer of this hard drive, has implemented various features to enhance the reliability and durability of this drive.
One of the key features is the usage of advanced vibration and shock resistance technologies, this allows the drive to operate in high-vibration environments and still maintain high data integrity.
Another feature is the usage of RAID-specific, time-limited error recovery (TLER) which helps to prevent drive fallout caused by extended hard drive error-recovery processes.
Seagate also uses a technology called “PowerChoice” which allows the user to adjust the drive’s idle power consumption to suit the specific requirements of their environment.
It is also worth noting that Seagate typically offer a 5-year warranty on their hard drives, which is an industry standard for enterprise hard drives, and this drive is no exception.
That being said, it’s important to keep in mind that the actual reliability of any hard drive will depend on the specific usage conditions, environmental factors and the proper maintenance of the drive.
General Information:
Manufacturer : Seagate
Manufacturer Part : 2KG213-003
Product Line : Exos X16
Product Name : Exos X16 14TB Hard Drive
Type : Hard Disk Drive (HDD)
Sub-Type : SAS-12GBPS
BEST-FIT APPLICATIONS :
Hyperscale Applications/cloud Data Centers
Massive Scale-out Data Centers
Big Data Applications
High-capacity Density Raid Storage
Mainstream Enterprise External Storage Arrays
Distributed File Systems, Including Hadoop And Ceph
Enterprise Backup And Restore— D2D, Virtual Tape
Centralized Surveillance
Key Features:
Storage Capacity : 14 TB
Enclosure : Internal
Interface : SAS-12GBPS
512e Sector Size (Bytes Per Sector) : 512
4kn Sector Size (Bytes Per Sector) : 4096
Drive Dimensions : 3.5 Inch
Mtbf : 2.5 Million Hours
Helium Sealed-drive Design : Yes
Superparity : Yes
Low Halogen : Yes
Powerchoiceâ„¢ Idle Power Technology : Yes
Powerchoiceâ„¢ Power/performance Technology : Yes
Low Halogen/hot-plug Support : Yes
Organic Solderability Preservative : Yes
Rsa 2048 Firmware Verification (SD&D) : Yes
DRIVE PERFORMANCE :
Interface Access Speed (GB/S) : 12.0, 6.0, 3.0
Sustained Data Transfer Rate Od (MAX): Up To 261, 249 MBPS
Random Read/write 4K QD16 WCD (IOPS) : 170/440
Average Latency : 4.16 MS
Interface Ports : Dual
Buffer : 256 MB
Rotational Speed : 7200 RPM
