Description
Product Overview of the Cisco Catalyst 3560X Series Switch
The Cisco WS-C3560X-48P-L is a part of the Catalyst 3560X Series, representing a powerful and versatile switch designed to meet the demands of modern network infrastructures. Equipped with 48 ports supporting 10/100/1000Base-T RJ-45 connections, Power Over Ethernet Plus (PoE+), a Universal Serial Bus (USB) port, and the ability to be rack-mounted in a 1U space, this Layer 2 manageable switch provides robust connectivity options and advanced management features.
The WS-C3560X-48P-L is a Cisco Catalyst switch model. The “3560X” in the model name indicates that it is part of the Cisco Catalyst 3560-X series, which is a line of fixed-configuration, enterprise-class switches that provide Layer 2 and basic Layer 3 connectivity for small and medium-sized businesses, as well as enterprise branch offices.
The “48P” in the model name indicates that the switch has 48 ports. These ports can be configured as a combination of Gigabit Ethernet (RJ-45) and Small Form-Factor Pluggable (SFP) ports. The “L” at the end of the model name indicates that the switch is a “Lite” version. This means the switch supports a lower set of features compared to another version of 3560X series switches.
This item is a Layer 2 managed switch, which means it can forward Ethernet frames based on the MAC addresses of the devices connected to its ports, and it can be configured and managed using a variety of management protocols, such as SNMP and CLI.
Understanding Switch Ports and PoE+
Switches like the WS-C3560X-48P-L serve as essential networking devices that facilitate multiple device connections within a network. The inclusion of PoE+ in this switch is particularly significant, as it allows the switch to deliver both data and electrical power over Ethernet cables to devices like IP cameras and VoIP phones.
Features of Cisco WS-C3560X-48P-L Catalyst 3560X Series Switch48 Ports Supporting 10/100/1000Base-T RJ-45 Connections
The switch offers 48 ports supporting various Ethernet speeds (10/100/1000Base-T) for connecting multiple devices to the network.
Power Over Ethernet Plus (PoE+)
The PoE+ capability allows the switch to deliver power along with data to connected devices, simplifying the deployment of devices like IP cameras and VoIP phones.
Universal Serial Bus (USB) Port
The USB port provides additional connectivity options for configuring the switch or connecting external devices.
1U Rack-Mountable Design
Designed for rack installation, the 1U size ensures efficient space utilization in data centers or networking setups.
Layer 2 Manageable Switch
As a Layer 2 switch, it operates at the data link layer, facilitating efficient traffic management within the local network.
Network Interface Module (NIM)
The inclusion of a Network Interface Module provides additional flexibility for expansion or connectivity options.
Importance of PoE+ in Networking Environments
The inclusion of PoE+ in a switch offers several advantages:
Simplified Deployment of Powered Devices
PoE+ enables the deployment of devices like IP cameras and VoIP phones without the need for separate power sources, simplifying installation.
Flexibility in Device Placement
Devices can be deployed in locations without immediate access to power outlets, providing flexibility in device placement.
Cost-Efficiency
PoE+ reduces the need for additional power infrastructure, contributing to cost savings in deployment.
Benefits of Using Cisco WS-C3560X-48P-L Catalyst 3560X Series SwitchVersatile Connectivity Options
With 48 RJ-45 ports supporting various Ethernet speeds, the switch accommodates a diverse range of devices and network requirements.
Power and Data Delivery (PoE+)
The PoE+ capability simplifies device deployment by delivering both power and data over Ethernet cables.
USB Connectivity
The USB port provides additional connectivity options for configuring the switch or connecting external devices.
Rack-Mountable Design
The 1U rack-mountable design ensures efficient space utilization in data centers or networking setups.
Use Cases for Cisco WS-C3560X-48P-L Catalyst 3560X Series SwitchEnterprise Networks
Ideal for medium to large enterprises requiring robust connectivity and efficient traffic management within the local network.
IP Surveillance Deployments
Suitable for IP surveillance deployments where PoE+ simplifies the installation of IP cameras by delivering both power and data over a single cable.
VoIP Phone Networks
Efficient for VoIP phone networks, providing both data and power to connected devices, reducing the need for additional power sources.
Performance and Reliability
This item is a Cisco Catalyst 3560X series switch. This switch is designed for enterprise-level network environments and offers a variety of features to enhance performance and reliability.
The switch has 48 ports, all of which are Fast Ethernet or Gigabit Ethernet ports. It supports both Layer 2 and Layer 3 switching, meaning it can handle both data link and network layer traffic. Additionally, the switch supports a variety of advanced features such as Quality of Service (QoS), Virtual LANs (VLANs), and Link Aggregation Control Protocol (LACP).
The WS-C3560X-48P-L also has several reliability features to ensure that the network remains up and running. These include:
- Hot-swappable power supplies and fans
- Redundant power supply options
- Support for Cisco StackWise Plus technology, which allows multiple switches to be connected and managed as a single logical device
- The ability to run Cisco IOS Software, which includes a variety of security and management features
Interface Provided for Digital Workplace
The WS-C3560X-48P-L is a Cisco Catalyst 3560-X series switch. It is a Layer 2 managed switch, which means it can forward and filter data based on MAC addresses and handle VLANs to segment networks. The switch has 48 Ethernet ports, which can be configured for different speeds (e.g. 10/100/1000 Mbps) and modes (e.g. access, trunk). Additionally, the switch has some uplink ports that can be configured for higher-speed connections such as 10 Gigabit Ethernet.
This switch can be used in a digital workplace to provide connectivity for a variety of devices such as computers, servers, IP phones, and cameras. The switch can be configured to provide advanced features such as Quality of Service (QoS) to prioritize different types of traffic, security features to prevent unauthorized access, and Power over Ethernet (PoE) to power devices such as IP phones. The switch can be managed and configured through a web interface or a command-line interface.
The L in the name indicates that this model has a LAN Base software image, which means it supports the most common network protocols such as IP, IPv6, and Spanning Tree Protocol, but might have limited support for advanced features compared to other models.
General Information about this Cisco WS-C3560X-48PF-L
- Manufacturer: Cisco
- Part Number or SKU# WS-C3560X-48PF-L
- Product Line: Catalyst
- Product Series: 3560-X
- Product Type: Ethernet Switch
Interfaces/Ports for 48 Ports Ethernet Switch
- Total Number of Network Ports: 48
- Number of PoE (RJ-45) Ports: 48
- Port/Expansion Slot Details: 48 x Gigabit Ethernet Network
Performance of Catalyst 3560-X Managed Switch
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 10/100/1000Base-T
I/O Expansions of Layer 2 Switch
- Number of Total Expansion Slots: 2
Features
- Hot swap module replacement, layer 2 switching, dynamic IP address assignment, DHCP support, power over Ethernet (PoE), auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), PoE+, Per-VLAN Spanning Tree Plus (PVST+), Uni-Directional Link Detection (UDLD), Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN)
Environmental Parameters
- Min Operating Temperature: 23 °F
- Humidity Range Operating: 5 – 95% (non-condensing)
- Min Storage Temperature: -40 °F
- Max Storage Temperature: 158 °F
Network & Communication
- Layer Supported: 2
Management & Protocols
- Manageable: Yes
Memory
- DRAM: 256 MB
- Flash Memory: 64 MB
Power Description
- Power Device: Internal power supply
- PoE (RJ-45) Port: Yes
- Input Voltage: 110 V AC
- Input Voltage: 220 V AC
Miscellaneous
- Rack Mounting Kit: Optional
- MTBF: 149,594 hours
- Compliant Standards: TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
In general, the Cisco WS-C3560X-48P-L Catalyst 3560X Series Switch, featuring 48 ports supporting 10/100/1000Base-T RJ-45 connections, PoE+ capability, a USB port, a 1U rack-mountable design, and Layer 2 manageability, stands as a powerful and versatile solution for modern networking needs. Its diverse connectivity options, PoE+ functionality, USB connectivity, and rack-mountable design make it suitable for various applications, including enterprise networks, IP surveillance deployments, and VoIP phone networks. Cisco’s commitment to reliable and scalable networking solutions positions the Catalyst 3560X switch as an essential component in contemporary network infrastructures.
