High Performance of Switch
The Cisco WS-C2960S-48LPS-L is a fixed-configuration, stackable Gigabit Ethernet switch that provides 48 ports of 10/100/1000 Mbps connectivity. It is part of the Cisco Catalyst 2960-S series of switches, which are designed for enterprise-class access and distribution applications. This Product switch supports a number of features and capabilities to help improve network performance, including:
- IEEE 802.3af Power over Ethernet (PoE) and Cisco Universal PoE (UPOE) for powering IP phones, wireless access points, and other PoE-enabled devices
- Quality of Service (QoS) for prioritizing network traffic and improving the performance of real-time applications
- Energy Efficient Ethernet (IEEE 802.3az) for reducing power consumption and improving energy efficiency
- Jumbo frames (up to 9216 bytes) for improved performance in environments with large file transfers
- Cisco StackPower, which allows for the sharing of power resources between stackable switches
Port Configurations and Capabilities of the Switch
The Cisco WS-C2960S-48LPS-L Catalyst 2960S 48 Ports Gigabit PoE Switch has the following port configurations and capabilities:
- 48 Gigabit Ethernet ports: These ports support data transfer speeds of up to 1000 Mbps and can be used to connect devices such as computers, servers, printers, and other network devices.
- PoE/PoE+ capability: The switch supports Power over Ethernet (PoE) and Power over Ethernet Plus (PoE+) technologies, which allows it to provide power to connected devices over the Ethernet cables. With PoE, the switch can provide up to 15.4 watts of power per port, while with PoE+ it can provide up to 30 watts of power per port.
- 4 SFP ports: These Small Form-Factor Pluggable (SFP) ports allow for fiber optic connectivity, which can be useful for connecting devices over longer distances or in environments where electromagnetic interference (EMI) may be a concern.
- Port security: The switch supports various port security features such as MAC address filtering, port-based authentication, and 802.1x authentication, which can help to prevent unauthorized access to the network.
- VLAN support: The switch supports Virtual LAN (VLAN) technology, which allows for logical segmentation of the network and can help to improve network security and performance.
- Quality of Service (QoS): The switch supports QoS features such as traffic prioritization and classification, which can help to ensure that critical applications receive the necessary bandwidth and network resources.
- Link aggregation: The switch supports link aggregation technology, which allows for the grouping of multiple physical ports into a single logical port for increased bandwidth and redundancy.
VLANs and Trunking Supported by the Switch
The Cisco WS-C2960S-48LPS-L Catalyst 2960S 48 Ports Gigabit PoE Switch supports both VLANs and trunking.
VLANs: The switch supports IEEE 802.1Q VLAN tagging, which enables the creation of multiple VLANs on a single physical switch. This allows the switch to separate network traffic into different VLANs, which can improve network performance, increase security, and simplify network management. The switch supports up to 4096 VLANs.
Trunking: The switch supports IEEE 802.1Q trunking, which allows multiple VLANs to be carried over a single trunk link between switches. This enables the switch to extend VLANs across the network and support inter-VLAN routing. The switch also supports the Cisco proprietary Dynamic Trunking Protocol (DTP), which allows the switch to negotiate the trunking mode with other Cisco switches.
General Information about Cisco this WS-C2960S-48LPS-L
- Manufacturer: Cisco
- Model Number or SKU# WS-C2960S-48LPS-L
- Product Line: Catalyst
- Product Series: 2960
- Product Type: Ethernet Switch
Interfaces/Ports for 48 Ports Ethernet Switch
- Total Number of Network Ports: 48
- Number of PoE (RJ-45) Ports: 48
- Port/Expansion Slot Details: 48 x Gigabit Ethernet Network
- Port/Expansion Slot Details: 4 x Gigabit Ethernet Expansion Slot
Performance of Catalyst 2960 Managed Switch
- Media Type: SupportedOptical Fiber Twisted Pair
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 10/100/1000Base-T
I/O Expansions of Catalyst 2960 Switch
- Number of Total Expansion Slots: 5
- Expansion Slot Type: SFP
- Expansion Slot Type: Stacking Module
- Number of SFP Slots: 4
Network & Communication
- Layer Supported: 2
Management
- IEEE 802.1p QoS
- DHCP
- IEEE 802.1Q VLAN
- RMON
- CLI
- CiscoWorks LAN Management Solution
- SNMPv3
- Syslog
Memory
- Standard Memory: 128 MB
- Memory Technology: DRAM
- Flash Memory 64 MB
Power Description
- PoE (RJ-45) Port Yes
- Power Source Power Supply
- Redundant Power Supply Yes
Dimensions and Weight
- Height 1.8 inch
- Width 17.5 inch
- Depth 15.2 inch
- Weight 12.50 LBS
About Refurbished Products
Different Types of Switches
Networking switches vary widely depending on the number of devices they can support, network bandwidth/speed, and form factor. Switches for small offices will have anything between 4 and 8 ports and can fit on a desk. For larger office network implementation, switches may have 24 ports, 48 ports, 96 ports, and 128 ports and are rack-mountable between 1U and 4U. Switches come in different types depending on the network speed and tasks they support. These include 40/100 Gbps, 10 Gigabit (up to 10000 Mbps), Gigabit Ethernet (up to 1000 Mbps), Power over Ethernet, and Fast Ethernet (10/100 Mbps).
Unmanaged Switches
The unmanaged switches offer fixed configuration on a plug-and-play basis. It is the most basic switch and there are a few choices in the market. These switches are affordable, but the basic features make them inappropriate for enterprise applications.
Managed Switches
The number of features and level of functionality improves with managed switches, making them ideal for enterprise and business applications. These switches are built with the command-line interface for ease of configuration. Equally, they support SNMP agents that come in handy when troubleshooting network issues.
The security on managed switches is better and will protect different types of traffic. Other features include support for virtual LANs, IP routing, and quality of service settings. Managed switches are more expensive compared to all other types of switches.
Smart Switches
Smart switches refer to switches that possess more features than those of unmanaged switches but do not have the full features of managed switches. Smart switches are more cost-effective than managed switches.
Some of the limitations of the smart switches are a lack of telnet access support, Web GUIs, and a lack of many features for VLANs. They are affordable compared to a fully managed switch and are suitable for a smaller computer network.
Modular Switches
Modular switches allow the addition of expansion modules as the network expands. The expansion modules allow for more networked devices but are application-specific. They may include wireless access points, firewalls, or network analysis tools. The flexibility of a modular networking switch comes at a higher cost.
Here, you can check more available conditions of your desired product WS-C2960S-48LPS-L at a competitive price. We are trying our best to meet your needs on the enterprise-level computer, server, data centre, and networking hardware. You are welcome to ask our live chat or get live representative support over the phone.
