Description
Scalable and Reliable of HPE SFP 24 Ports Switch
Scalable refers to the ability of a system or device to adapt to changes in demand or to grow as needed. In the case of the J9773-61001 HPE 2530-24G Ports PoE+ 4 Gigabit SFP Ports Managed Switch, it means that the switch can handle a large number of network connections and devices without compromising performance. This is achieved through features such as support for VLANs, Quality of Service (QoS), and Link Aggregation.
Reliability refers to the ability of a system or device to perform its intended function consistently and without interruption. The J9773-61001 HPE 2530-24G Ports PoE+ 4 Gigabit SFP Ports Managed Switch is designed with reliability in mind, featuring redundancy in power and cooling, as well as advanced security features such as Access Control Lists (ACLs) and Network Address Translation (NAT). Additionally, the switch is designed to be easy to manage, with an intuitive web-based interface and support for remote management.
IEEE 802.1x Authentication for Secure Network Access
IEEE 802.1x is a standard for network access control that allows secure and authenticated access to a network. It is used to ensure that only authorized devices and users are able to connect to a network, and it provides a way to monitor and control access to the network.
The HPE 2530-24G Ports PoE+ 4 Gigabit SFP Ports Managed Switch supports IEEE 802.1x authentication, which means that it can be configured to require authentication from devices that attempt to connect to the network. This is done by using a RADIUS (Remote Authentication Dial-In User Service) server, which is responsible for authenticating devices and users.
When a device attempts to connect to the network, the switch will send an authentication request to the RADIUS server. The RADIUS server will then verify the device’s credentials and determine if it is authorized to connect to the network. If the device is authorized, the switch will allow it to connect to the network, and the device will be able to access network resources. If the device is not authorized, the switch will deny access to the network.
In addition to providing secure access to the network, IEEE 802.1x authentication also allows for monitoring and control of access to the network. For example, an administrator can use the switch’s management interface to view which devices are currently connected to the network, and can also configure the switch to restrict access to certain devices or users.
Easy Management and Configuration
The J9773-61001 HPE 2530-24G Ports PoE+ 4 Gigabit SFP Ports Managed Switch is a network switch that is designed for easy management and configuration. It has 24 Gigabit Ethernet ports and 4 Gigabit SFP ports, as well as PoE+ capability, which allows it to power connected devices over Ethernet. It is a managed switch, meaning it can be configured and managed through a web interface or command-line interface. This allows for more advanced features such as VLANs, Quality of Service, and port-based security. The switch also supports HPE’s Smart Managed Pro feature set, which includes advanced security and network management capabilities.
General Information J9773-61001
- Manufacturer: HPE
- Part Number or SKU# J9773-61001
- Category: Networking
- Sub-Category: Switch 24 Port
- Device Type : Switch – 24 Ports – Managed
- Enclosure Type : Desktop, Rack-Mountable, Wall-Mountable – 1U
- Processor : 1 X Arm : 800 Mhz
- Ram : 128 Mb – DDR3 SDRAM
- Flash Memory : 256 Mb
Networking
- Ports : 24 X 10/100/1000 + 4 X Gigabit SFP
- Power Over Ethernet (POE) : POE+
- Performancethroughput : 41.6 Mpps Switching Capacity : 56 Gbps
- Mac Address Table Size : 16000 Entries
- Jumbo Frame Support : 9220
- Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Snmp 2c, Http, Tftp, Ssh-2, Cli
- Encryption Algorithm : SSL
- Authentication Method : Radius, Tacacs+, Secure Shell V.2 (Ssh2)
- Compliant Standards : IEEE 802.3, IEEE 802.3U, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1P, IEEE 802.3X, IEEE 802.3AD (LACP), IEEE 802.1W, IEEE 802.1X, IEEE 802.1S, IEEE 802.1AB (LLDP), IEEE 802.3AT, IEEE 802.3AZ
Expansion / Connectivity
- Interfaces :
- 24 X 10Base-T/100Base-Tx/1000Base-T – RJ-45 – POE+
- 4 X SFP+
- Management : 1 X Console – RJ-45
