Description
More Information on the Cisco AIR-AP3702I-UXK9 Switch
In the fast-paced world of networking, the Cisco AIR-AP3702I-UXK9 Aironet 3702I stands out as a high-performance Wireless Access Point (WAP). This device is designed to meet the demanding connectivity needs of modern environments, boasting features like IEEE 802.11ac, 1.3 Gbit/s data transfer rates, and advanced technologies such as Multiple-Input Multiple-Output (MIMO) and Beamforming. In this comprehensive guide, we’ll delve into the key aspects of the Cisco AIR-AP3702I-UXK9, exploring its specifications, capabilities, and how it contributes to efficient networking.
SpecificationsIEEE 802.11ac Standard
The Cisco AIR-AP3702I-UXK9 adheres to the IEEE 802.11ac standard, representing a significant advancement in wireless technology. This standard operates on the 5 GHz frequency band, enabling higher data transfer rates compared to its predecessors. The utilization of 802.11ac ensures that this wireless access point delivers faster and more reliable connectivity, making it suitable for bandwidth-intensive applications and large-scale networks.
Impressive Data Transfer Rates
With a staggering 1.3 Gbit/s data transfer rate, the Cisco Aironet 3702I sets a high bar for wireless performance. This exceptional speed is crucial for supporting a multitude of devices simultaneously, ensuring a seamless user experience in environments with high network traffic. Whether it’s streaming high-definition content or conducting video conferences, the AIR-AP3702I-UXK9 excels in providing a swift and responsive connection.
Advanced TechnologiesMultiple-Input Multiple-Output (MIMO)
One of the standout features of the Cisco AIR-AP3702I-UXK9 is its implementation of Multiple-Input Multiple-Output (MIMO) technology. MIMO enhances wireless communication by using multiple antennas for both transmission and reception. This results in improved data throughput and increased reliability. The Aironet 3702I’s MIMO capabilities empower it to handle multiple data streams concurrently, optimizing the overall network performance.
Beamforming Technology
Beamforming is a technology that further enhances the efficiency of wireless communication. By focusing the signal in the direction of the receiving device, Beamforming reduces interference and increases the signal strength. The Cisco AIR-AP3702I-UXK9 utilizes Beamforming technology to create a more directed and efficient wireless connection. This is particularly beneficial in environments with challenging layouts or obstacles, ensuring a stable and robust network.
Networking CapabilitiesDual-Band Support
The AIR-AP3702I-UXK9 operates on both the 2.4 GHz and 5 GHz frequency bands. This dual-band support is essential for accommodating a diverse range of devices with varying wireless capabilities. The 2.4 GHz band provides better coverage over longer distances, while the 5 GHz band offers higher data transfer rates. This flexibility enables the Aironet 3702I to adapt to the specific needs of different applications and devices on the network.
Seamless Integration with IEEE Standards
As an IEEE 802.11ac compliant device, the Cisco Aironet 3702I ensures compatibility with industry standards. This adherence to established norms facilitates seamless integration into existing networks and ensures interoperability with a wide range of devices. The IEEE standards are the backbone of modern networking, and the AIR-AP3702I-UXK9’s alignment with these standards positions it as a reliable and versatile wireless access point.
Good Side of This Wireless Access Point
- High-speed wireless connectivity: The AIR-AP3702I-UXK9 offers 1.3Gbps wireless speeds, providing fast and reliable wireless access for devices in the network.
- Multiple radios: The access point has dual-band radios that support both 2.4GHz and 5GHz frequencies, providing flexibility for different wireless devices and applications.
- Advanced security features: The access point comes with built-in security features such as WPA2, WPA3, and 802.1x authentication, providing robust protection against potential threats.
- Easy to manage and configure: The access point is easy to manage and configure through the web-based interface or the Cisco Wireless Control System (WCS).
- Support for high-density environments: The access point is designed to handle high-density environments, providing reliable wireless coverage and capacity for large numbers of users.
- Flexible deployment options: The access point can be deployed as a standalone device or as part of a Cisco wireless network, providing flexibility for different network requirements.
The Cisco 3700 Series Wireless Access Point this product has several positive features that make it a great choice for businesses and organizations. Some of the good sides of this access point include:
- High-Speed Wireless Connectivity: This product supports 802.11ac Wave 2 technology, providing high-speed wireless connectivity for devices such as laptops, smartphones, and tablets. This allows for faster data transfer and improved overall performance.
- Advanced Security Features: The access point includes built-in security features such as WPA2-Enterprise, which provides robust security for wireless networks. It also includes rogue AP detection and containment, which helps to prevent unauthorized access points from connecting to the network.
- Flexible Deployment: This item can be deployed in a variety of ways, including standalone, as part of a wireless LAN controller network, or as part of the Cisco FlexConnect architecture. This allows for flexibility in terms of network design and deployment.
- Easy Management: The access point can be managed using the Cisco Wireless Control System (WCS) or the Cisco Prime Infrastructure. This allows for easy management and monitoring of the wireless network, reducing the time and effort required to maintain and troubleshoot the network.
- High-Performance Antennas: The access point includes integrated high-performance antennas that provide wide coverage and improved signal strength, making it ideal for large or complex environments.
Compliant Standards
The AIR-AP3702I-UXK9 Cisco 3700 Series 1.3GBPS Wireless Access Point is a high-performance wireless access point that is compliant with a variety of industry standards. These standards include:
- IEEE 802.11a/b/g/n/ac: This standard defines the specifications for wireless LANs (WLANs) and is commonly used in enterprise networks. The AIR-AP3702I-UXK9 is compliant with the 802.11ac standard, which provides faster data rates and improved coverage compared to previous versions.
- IEEE 802.3af/at Power over Ethernet (PoE): This standard allows the access point to be powered through an Ethernet cable, eliminating the need for a separate power source. This product is compliant with both the 802.3af and 802.3at PoE standards, which provide different levels of power to the device.
- Cisco FlexConnect: This Cisco proprietary feature allows the access point to function in both centralized and distributed modes, providing flexibility for different deployment scenarios.
- Cisco CleanAir: This Cisco proprietary feature provides advanced wireless interference detection and mitigation capabilities to improve overall network performance and reliability.
- Cisco Wireless Location Services: This Cisco proprietary feature allows for the accurate location tracking of wireless devices within the network, providing valuable information for security and network management purposes.
- Cisco Identity Services Engine (ISE) Compatible: This Cisco proprietary feature allows the access point to integrate with Cisco ISE for user-based security and policy enforcement.
Key Information for Cisco AIR-AP3702I-UXK9
- Manufacturer: Cisco
- Model Number or SKU# AIR-AP3702I-UXK9
- Product Type: Wireless Access Point
- Interface Type: 1.3GBPS
Technical Information
- Wireless LAN Standard IEEE 802.11ac
- Wireless Transmission Speed 1.3 Gbit/s
- MIMO Technology Yes
- Beamforming Technology Yes
Interfaces / Ports
- Ethernet Port Yes
- Fast Ethernet Port Yes
- Gigabit Ethernet Port No
- 10Gigabit Ethernet Port No
- PoE (RJ-45) Port No
- VGA No
- HDMI No
- USB No
- Powerline No
- Management Port Yes
Power Description
- Power Source: PoE+
In general, the Cisco AIR-AP3702I-UXK9 Aironet 3702I Wireless Access Point is a powerhouse in the realm of wireless networking. Its adherence to the IEEE 802.11ac standard, impressive data transfer rates, and advanced technologies like MIMO and Beamforming make it a top choice for organizations seeking high-performance wireless solutions. Whether deployed in enterprise environments, educational institutions, or healthcare facilities, the AIR-AP3702I-UXK9 delivers robust and reliable connectivity, contributing to the seamless operation of modern networks.
