Description
Product Overview
In the world of enterprise-level servers, the UCS-ML-1X324RU-A 32GB 1x32gb 2133mhz Pc4-17000 Cl15 Ecc Registered Quad Rank DDR4 SDRAM 288-Pin Lrdimm Memory Module for Server, made by Cisco, is a highly regarded option. In this article, we’ll go over what each of those technical specifications means, and why they’re important for servers.
The UCS-ML-1X324RU-A is a part number that refers specifically to this memory module. It’s important to know the exact part number when purchasing or installing a memory module, as different part numbers can have different specifications, even if they look identical on the outside.
32GB
The first specification listed for this memory module is 32GB. This refers to the amount of memory that the module can store. In the context of servers, more memory generally means better performance, as it allows more data to be stored and processed at once.
1x32gb
The “1x32gb” specification means that this memory module has one individual 32GB module. Some memory modules come with multiple smaller modules, such as 2x16gb, but this particular module has one larger module. This can be important to know when determining how many memory slots are available on a server, and how many of them are already filled.
2133mhz
The 2133mhz specification refers to the speed of the memory module. Specifically, it means that the module is rated to operate at a speed of 2133 megahertz. This can affect the overall performance of a server, as faster memory allows for quicker data access and transfer.
PC4-17000
The PC4-17000 specification is a bit more technical, but it refers to the type of memory module. Specifically, it indicates that this is a DDR4 memory module, which is the most recent generation of DDR (Double Data Rate) memory. The “PC4-17000” part of the specification refers to the theoretical maximum bandwidth of the memory module, which is 17GB/s.
CL15
The CL15 specification refers to the CAS (Column Address Strobe) Latency of the memory module. Essentially, this indicates how quickly the memory module can respond to requests for data. A lower CL number generally means faster performance.
ECC Registered
The ECC Registered specification refers to a type of error correction that is built into the memory module. ECC (Error-Correcting Code) memory can detect and correct errors in the data that is stored in memory, which can be important for servers that need to maintain high levels of data integrity. Registered memory, meanwhile, is a type of memory that uses a buffer to improve stability and reduce the load on the memory controller.
Quad Rank
The Quad Rank specification refers to the way that the memory module is organized internally. Specifically, it means that the module has four memory banks on it. This can be important to know when determining compatibility with a particular server, as some servers may have limitations on the number of ranks that can be installed.
DDR4 SDRAM
As mentioned earlier, the DDR4 SDRAM specification refers to the type of memory module. DDR4 SDRAM is the most recent generation of DDR memory, and it offers higher bandwidth and lower power consumption than previous generations.
288-Pin LRDIMM
The 288-Pin LRDIMM specification refers to the physical design of the memory module. Specifically, it means that the module has 288 pins, and it uses the LRDIMM (Load-Reduced Dual Inline Memory Module) design. LRDIMM memory uses a buffer to reduce
General Information about the Cisco UCS-ML-1X324RU-A
- Manufacturer: Cisco
- Part Number or SKU# UCS-ML-1X324RU-A
- Type: Memory (RAM)
- RAM Type: PC4-17000
- Product Name: 32GB DDR4 SDRAM Memory Module
Technical Information
- Storage Capacity : 32GB
- Memory Technology : DDR4 SDRAM
- Number Of Modules : 1 X 32GB
- Memory Speed : 2133mhz DDR4-17000/PC4-17000
- Data Integrity CHECK : ECC CHIPKILL
- Signal Processing : Registered, Quad Rank
- Cas Latency Timings : Cl15
- Voltage: 1.2v
Dimensions & Weight
- Height: 0.75 Inch
- Width: 3.5 Inch
- Depth: 7.8 Inch
- Weight: 1 Lbs
Contact us or ask for live chat/help if you have any questions about the compatibility of this item to ensure the model’s matching features with your current system.
