The Cisco WS-C3560X-24P-E is a member of the Catalyst 3560 Series, representing a high-performance Ethernet switch designed for various networking needs. It comes equipped with 24 ports, supporting a mix of 10/100/1000Base-TX connections and providing Power over Ethernet Plus (PoE+) capabilities. This Layer 3 switch is rack-mountable, occupying 1U of space in a standard server rack.
Purpose of Catalyst 3560 Ethernet Switch
The Catalyst 3560 Series from Cisco is renowned for delivering reliable and scalable network solutions. The WS-C3560X-24P-E, in particular, is tailored to address the demands of modern networking environments, offering a combination of high-speed connectivity, power provisioning, and advanced management features.
Understanding the Technical Specifications24-Ports 10/100/1000Base-TX RJ-45
- 24 Ports: This switch provides a total of 24 ports, offering flexibility for connecting various devices to the network.
- 10/100/1000Base-TX: The switch supports Gigabit Ethernet speeds (10/100/1000 Mbps), ensuring high data transfer rates for connected devices.
- RJ-45 Connectivity: The RJ-45 connectors are standard network jacks commonly used for Ethernet connections.
Power Over Ethernet Plus (PoE+)
- PoE+: Power over Ethernet Plus is a feature that allows the switch to deliver both data and electrical power to compatible devices, such as IP phones, cameras, or access points, over the Ethernet cables.
Manageable Layer 3
- Manageable: The switch is equipped with management capabilities, providing administrators with control over network configurations, security, and monitoring.
- Layer 3: As a Layer 3 switch, it operates at the network layer of the OSI model, offering routing capabilities for efficient traffic management.
Rack-Mountable 1U
- Rack-Mountable: This switch is designed to be installed in a standard server rack, optimizing space and facilitating organized network infrastructure.
- 1U: The 1U designation indicates that the switch occupies 1 rack unit of vertical space in the rack, ensuring efficient use of rack space.
Importance of PoE+ and Layer 3 in NetworkingPower Over Ethernet Plus (PoE+)
- PoE+ simplifies the deployment of networked devices by eliminating the need for separate power sources. Devices like IP phones and cameras can receive power through the same Ethernet cables used for data transmission.
Layer 3 Functionality
- Layer 3 switches provide routing capabilities, allowing for more efficient traffic management within a network. This is particularly useful in larger networks where multiple subnets or VLANs are present.
Application in Network EnvironmentsEnterprise Networks
- The Catalyst 3560 Series, including the WS-C3560X-24P-E, is well-suited for deployment in enterprise networks, offering a robust and scalable solution for connecting a variety of devices.
IP Telephony and Surveillance
- With PoE+ capabilities, the switch is ideal for supporting IP telephony systems and surveillance cameras, streamlining the deployment of these devices in an organization.
Benefits of Cisco WS-C3560X-24P-E Catalyst 3560High-Speed Connectivity
- With Gigabit Ethernet ports, the switch ensures high-speed connectivity for devices, supporting bandwidth-intensive applications and data transfers.
Simplified Device Deployment
- PoE+ simplifies the deployment of networked devices by providing both data and power over a single Ethernet cable, reducing the need for additional power sources.
Efficient Network Management
- The Layer 3 capabilities enable efficient routing and network management, allowing administrators to control traffic and optimize network performance.
Stackable design and scalability options
The WS-C3560X-24P-E Cisco Catalyst 3560-X Ethernet Switch is designed with stackable technology, allowing multiple switches to be connected and managed as a single unit. This stackable design provides scalability options for networks, allowing the user to add more switches as the network grows and expands.
When multiple switches are stacked together, they form a single logical unit, which can be managed through a single IP address. This eliminates the need for individual management of each switch and allows for more efficient network management. The switch also supports stacking through Cisco StackWise technology, which provides a high-speed stacking bus for fast and efficient communication between switches in the stack.
In terms of scalability, the WS-C3560X-24P-E supports up to 9 switches in a stack, providing up to 216 Gigabit Ethernet ports. This allows for a large number of devices to be connected to the network and provides the flexibility to expand the network as needed.
Additionally, the switch supports a variety of uplink options, including Gigabit Ethernet and 10 Gigabit Ethernet ports, providing a range of connectivity options for different network requirements.
Advanced security features
The WS-C3560X-24P-E Cisco Catalyst 3560-X 24 Ports Ethernet Switch offers advanced security features to protect the network against unauthorized access and threats. Some of the key advanced security features include:
- Access Control Lists (ACLs): The switch supports ACLs to restrict access to the network based on various parameters such as IP address, protocol, and port number.
- Port Security: This feature allows the user to set a maximum number of MAC addresses for a specific port, preventing unauthorized devices from connecting to the network.
- IEEE 802.1x Authentication: The switch supports IEEE 802.1x authentication to ensure that only authorized devices are able to access the network.
- DHCP Snooping: This feature prevents malicious DHCP servers from distributing incorrect IP addresses to devices on the network.
- Dynamic ARP Inspection (DAI): This feature prevents ARP cache poisoning attacks by validating ARP packets and ensuring that they are legitimate.
- IP Source Guard: This feature prevents unauthorized devices from using IP addresses that are not assigned to them.
- Storm Control: This feature helps to prevent network congestion by controlling the amount of broadcast, multicast, and unicast traffic that is allowed on the network.
- Cisco FlexStack: This feature allows the user to manage multiple switches as a single entity, simplifying the management of the network and enhancing security.
Quality of Service (QoS) and traffic management
The WS-C3560X-24P-E Cisco Catalyst 3560-X 24 Ports Ethernet Switch offers advanced Quality of Service (QoS) and traffic management capabilities to ensure that network traffic is prioritized and managed effectively.
QoS allows the user to assign different priorities to different types of traffic, such as voice, video, and data. This ensures that critical traffic, such as voice calls, is given priority over less critical traffic, such as file downloads. The switch supports various QoS features including Class of Service (CoS), Differentiated Services Code Point (DSCP), and Multi-Field Classification (MFC). Additionally, the switch supports Advanced Quality of Service (AQoS), which allows for more granular and efficient management of traffic.
Traffic management allows the user to control and monitor the flow of traffic on the network. The switch supports various traffic management features such as rate limiting, traffic shaping, and storm control. These features help to prevent network congestion and ensure that network resources are used efficiently. Additionally, the switch supports Flexible NetFlow (FNF), which allows for more detailed monitoring and analysis of network traffic.
The switch also supports advanced security features such as Access Control Lists (ACLs), Port Security, and IEEE 802.1x authentication to secure the network and protect against unauthorized access.
General Information about this Cisco WS-C3560X-24P-E
- Manufacturer: Cisco
- Model Number or SKU# WS-C3560X-24P-E
- Product Line: Catalyst
- Product Series: 3560-X
- Product Name Catalyst: 3560-X Ethernet Switch
- Product Type: Ethernet Switch
Interfaces/Ports
- Total Number of Network Ports: 24
- Token Ring Port: No
- LRE Port: No
- Uplink Port: No
- Bypass: No
- Modular: No
- Management Port: Yes
- USB: Yes
- Number of PoE+ (RJ-45) Ports: 24
Performance
- Media Type Supported: Twisted Pair
- Ethernet Technology: Gigabit Ethernet
- Network Technology: 10/100/1000Base-T
I/O Expansions
- Number of Total Expansion Slots: 1
- Shared SFP Slot: No
Network & Communication
- Layer Supported: 2
Memory
- Standard Memory: 256 MB
- Memory Technology: DRAM
- Flash Memory: 64 MB
Reliability
- MTBF: 181370 Hour
Power Description
- PoE (RJ-45) Port: Yes
- Input Voltage: 110 V AC
- Input Voltage: 220 V AC
- Power Source: Power Supply
- Redundant Power Supply: Yes
In summary, the Cisco WS-C3560X-24P-E Catalyst 3560 Ethernet Switch stands as a robust and versatile solution for modern networking needs. With 24 Gigabit Ethernet ports, PoE+ capabilities, Layer 3 functionality, and rack-mountable design, it addresses the requirements of enterprise networks, supporting high-speed connectivity and streamlined device deployment.
