Description
Product Overview of the
The 850383-001 HPE Intel Xeon E5-2698V4 is a high-performance processor designed for servers and workstations. It is part of the Intel Xeon E5-2600 V4 family of processors, which are designed for demanding data center and cloud applications. In this article, we will discuss the features and specifications of the 850383-001 HPE Intel Xeon E5-2698V4 processor in detail.
Processor Specifications
The 850383-001 HPE Intel Xeon E5-2698V4 processor is a 20-core processor that operates at a base clock speed of 2.2GHz. The processor supports Hyper-Threading technology, which allows each core to handle two threads simultaneously, resulting in a total of 40 threads. This is particularly useful for applications that require a large number of threads, such as data analysis, scientific simulations, and virtualization.
The processor has a large 50MB L3 cache, which is shared across all cores. The L3 cache is used to store frequently accessed data, which helps to reduce the time it takes for the processor to access data from the memory. This results in faster processing times and improved performance.
The 850383-001 HPE Intel Xeon E5-2698V4 processor uses the QPI (QuickPath Interconnect) interface to communicate with other components in the system, such as memory and I/O devices. The QPI interface operates at a speed of 9.6GT/s, which provides fast and efficient communication between the processor and other components.
The processor uses the Socket FCLGA 2011 interface, which is a type of LGA (Land Grid Array) socket. The LGA socket is used to connect the processor to the motherboard of the system. The Socket FCLGA 2011 interface is designed for high-performance processors and provides a large number of pins for efficient communication between the processor and motherboard.
The 850383-001 HPE Intel Xeon E5-2698V4 processor has a thermal design power (TDP) of 135W, which is the maximum amount of power that the processor can dissipate under normal operating conditions. The TDP is an important specification for server and workstation processors, as it determines the amount of heat generated by the processor, which in turn affects the cooling requirements of the system.
The processor is manufactured using a 14nm process technology, which is a type of semiconductor manufacturing process that allows for the creation of smaller and more efficient transistors. This results in a processor that is more energy-efficient and produces less heat than processors manufactured using older process technologies.
Features and Benefits of 2.2GHz processor
The 850383-001 HPE Intel Xeon E5-2698V4 processor offers several features and benefits that make it an ideal choice for high-performance server and workstation applications. Some of these features and benefits are:
- High Performance – The 20 cores and 40 threads of the processor provide high processing power for demanding applications, such as data analysis, scientific simulations, and virtualization.
- Large L3 Cache – The large 50MB L3 cache provides fast access to frequently accessed data, which improves performance and reduces processing times.
- Efficient Communication – The QPI interface provides fast and efficient communication between the processor and other components in the system, such as memory and I/O devices.
- Large Number of Pins – The Socket FCLGA 2011 interface provides a large number of pins for efficient communication between the processor and motherboard.
- Energy Efficient – The 14nm process technology used in the manufacturing of the processor makes it more energy-efficient and produces less heat than processors manufactured using older process technologies.
General Information
- Product manufacturer : HP
- Model Number or SKU# 850383-001
- Product model : E5-2698V4
- Product type : server processor
Technical Information
- Processor core : 20-core
- Clock speed : 2.2GHz
- Max turbo frequency : 3.6GHz
- Quick path interconnect(QPI) speed : 9.6GT/S
- No of QPI links: 2
- Instruction set : 64-bit
- Instruction set extensions : AVX 2.0
Cache Memory Detail
- L3 cache : 50MB
- Lithography : 14NM
- Max thermal design power (TDP) : 135W
- Compatible processor socket : FCLGA-2011
