Description
Detail Specification
The AJ716A HPE B-Series 8GBPS Shortwave FC 1 Pack SFP+ Transceiver Module is a fiber-optic transceiver module that is designed for use with HPE B-Series Fibre Channel (FC) switches. It is a small form-factor pluggable (SFP+) module that can be easily installed into a switch or other networking equipment.
This transceiver module is designed for use with shortwave fiber-optic cables and has a data transfer rate of 8 Gbps. It is compliant with the Fibre Channel FC-PI-4 standard and is compatible with SFP+ ports on HPE B-Series FC switches.
The module has a wavelength of 850nm and a maximum distance of 300 meters on OM3 multimode fiber and 400 meters on OM4 multimode fiber. It also has a low power consumption of 1.5 watts and a temperature range of 0 to 70 degrees Celsius.
The AJ716A HPE B-Series 8GBPS Shortwave FC 1 Pack SFP+ Transceiver Module is a reliable and high-performance solution for upgrading the data transfer rate of your FC network. It is also easy to install and maintain, making it a great choice for businesses of all sizes.
Reliability for Short Wave Transceiver
The AJ716A HPE B-Series 8GBPS Shortwave FC 1 Pack SFP+ Transceiver Module is a high-performance, reliable module designed for use in Fibre Channel (FC) networks. It is a Small Form-Factor Pluggable (SFP+) transceiver that supports data transfer rates of up to 8 Gbps and is compatible with the HPE B-Series FC SAN switches.
The module is designed for shortwave fiber optic cables, which means it can transmit data over longer distances than standard shortwave transceivers. This makes it ideal for use in large data centers or other environments where distance is a concern.
One of the key features of the AJ716A is its reliability. It is designed to meet rigorous industry standards and has undergone extensive testing to ensure it can withstand harsh operating conditions. The module is also built with advanced error correction technology, which helps to reduce the risk of data errors and ensure smooth data transmission.
General Compatibility
The AJ716A HPE B-Series 8GBPS Shortwave FC 1 Pack SFP+ Transceiver Module is a fiber channel transceiver that is compatible with HPE B-Series SAN switch and director class products. It allows for the connection of 8 Gbps Fibre Channel (FC) networks and supports shortwave (SW) optics, which have a maximum distance of 500 meters. This transceiver module is a single pack, meaning it includes one module per purchase. It is designed to work with SFP+ ports, which are small form-factor pluggable ports that are commonly used in networking equipment.
General Information about the HPE AJ716A
- Manufacturer: HPE
- Part Number or SKU# AJ716A
- Spare Part Number: 468507-001
- Transceiver Type: SFP+ Transceiver Module
- Form Factor: Plug-in Module
Networking for SFP+ Transceiver Module
- Connectivity Technology: Wired
- Cabling Type: Fibre Channel
- Data Link Protocol: 2Gb Fibre Channel, 4Gb Fibre Channel, 8Gb Fibre Channel
- Data Transfer Rate: 8 Gbps
- Optical Wave Length: 850 nm
- Max Transfer Distance: 984 ft
Expansion / Connectivity
- Interfaces: 1 x 8Gb Fibre Channel – LC multi-mode x 2
- Compatible Slots: 1 X SFP+
Dimensions
- Height: 0.5 inch
- Width: 2.2 inch
- Depth: 0.5 inch
- Weight: 1 LBS
Compatibility
Brocade 8Gb SAN Switch 8/12c, 8/24c, 8/24c Power Pack+ HP 8Gb Virtual Connect Fibre Channel Module for c-Class BladeSystem HPE 1606 Base Extension SAN Switch, 1606 Full Extension SAN Switch, 1606 Power Pack+ Extension SAN Switch, 32-port 8Gb/s Director Blade, 8/24 Base (16) Full Fabric Ports Enabled SAN Switch, 8/8 (8) Full Fabric Ports Enabled SAN Switch, 8/8 Base (0) e-port SAN Switch, SAN Switch 8/80 Power Pack+, SN6000B 16Gb 48-port/24-port Active Fibre Channel Switch, SN6000B 16Gb 48-port/24-port Active Power Pack+ Fibre Channel Switch, SN6000B 16Gb 48-port/48-port Active Fibre Channel Switch, SN6000B 16Gb 48-port/48-port Active Power Pack+ Fibre Channel Switch, SN8000B 32-port 8Gb/s Director Blade, SN8000B 48-port 8Gb/s Director Blade HPE BLc3000 Enclosure HPE BLc7000 Single-Phase Enclosure w/2 Power Supplies and 4 Fans w/8 Insight Control Environment Trial Licenses
w/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses HPE BLc7000 Three-Phase Enclosure w/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses HPE StorageWorks 2408 FCoE Base Converged Network Switch, 2408 FCoE Converged Network Switch Power Pack+, 8/8 (8) Full Fabric Ports Enabled SAN Switch, 8/8 Base (0) e-port SAN Switch, Encryption SAN Switch, MSL2024 Ultrium 1840, MSL2024 Ultrium 3000, MSL2024 Ultrium 3280, MSL4048 Ultrium 3000, MSL4048 Ultrium 3280, MSL8096 Ultrium 3280, SAN Director 16-port 8Gb Fibre Channel Blade, SAN Director 32-port 8Gb Fibre Channel Blade, SAN Director 48-port 8Gb Fibre Channel Blade, SAN Switch 8/24 Base, SAN Switch 8/40 Base, SAN Switch 8/40 Power Pack, SAN Switch 8/80 Base, SAN Switch 8/80 Power Pack HPE StoreFabric 8/24 8Gb Bundled Fibre Channel Switch
